CC2652PSIP
SWRS263A – FEBRUARY 2021 – REVISED JUNE 2022
txPower TX Power Setting (SmartRF Studio)
0x0014475E
0x00143957
0x0014592A
0x00144723
0x00104120
txPower TX Power Setting (SmartRF Studio)
0x6C3E
0x8A2A
0x581B
0x3863
0x26A3
0x269E
0x26E0
0x0ED8
0x08E5
0x08D0
0x08CF
0x00CC
0c00C9
0c08C7
0c08C6
32 Submit Document Feedback
Table 8-2. Typical TX Current and Output Power
CC2652PSIP at 2.44 GHz, VDDS = 3.0 V (Measured on CC2652XSIP_EM)
10
9
8
7
6
Table 8-3. Typical TX Current and Output Power
CC2652PSIP at 2.44 GHz, VDDS = 3.0 V (Measured on CC2652XSIP_EM)
5
4
3
2
1
0
-3
-5
-6
-9
-10
-12
-15
-18
-20
Product Folder Links:
Typical Output Power [dBm]
9.80
9.05
8.31
7.34
6.51
Typical Output Power [dBm]
4.27
3.70
2.72
1.68
0.71
-0.28
-3.04
-5.10
-6.32
-9.28
-9.96
-12.11
-15.29
-18.79
-20.25
CC2652PSIP
www.ti.com
Typical Current Consumption [mA]
33.06
28.08
24.67
21.09
18.67
Typical Current Consumption [mA]
10.67
10.04
9.28
8.80
8.38
7.96
7.19
6.65
6.41
5.94
5.85
5.61
5.34
5.12
5.05
Copyright © 2022 Texas Instruments Incorporated
