Bluetooth Low Energy - Transmit (Tx) - Texas Instruments SimpleLink CC2652PSIP Manual

CC2652PSIP
SWRS263A – FEBRUARY 2021 – REVISED JUNE 2022

8.11 Bluetooth Low Energy - Transmit (TX)

Measured on the CC2652xSIP-EM
DC/DC enabled and high power PA connected to V
All measurements are performed at the antenna input with a combined RX and TX path, except for high power PA which is
measured at a dedicated antenna connection. All measurements are performed conducted.
PARAMETER
General Parameters
Max output power,
high power PA, 10 Differential mode, delivered to a single-ended 50 Ω load through a balun
(1) (2)
dBm configuration
Output power
programmable range
Differential mode, delivered to a single-ended 50 Ω load through a balun
high power PA, 10
dBm configuration
Max output power,
Differential mode, delivered to a single-ended 50 Ω load through a balun
regular PA
Output power
programmable range, Differential mode, delivered to a single-ended 50 Ω load through a balun
regular PA
Spurious emissions and harmonics
f < 1 GHz, outside restricted bands
Spurious emissions,
f < 1 GHz, restricted bands ETSI
high-power PA, 10
f < 1 GHz, restricted bands FCC
(2)
dBm configuration
f > 1 GHz, including harmonics
Harmonics, Second harmonic
high-power PA, 10
Third harmonic
(1)
dBm configuration
f < 1 GHz, outside restricted bands
f < 1 GHz, restricted bands ETSI
Spurious emissions,
regular PA
f < 1 GHz, restricted bands FCC
f > 1 GHz, including harmonics
Second harmonic
Harmonics,
regular PA
Third harmonic
(1) To meet the FCC 15.247 Part 15 (US) harmonic requirement at full output power, the max allowable antenna gain is 1.9 dBi. Output
power is limited to 9 dBm when using a max antenna gain of 3.3 dBi.
(2) To meet the ETSI EN 300 328 (Europe) 10 dBm/MHz Power Spectral Density (PSD) requirement, output power is limited to 7 dBm and
6dBm when using a max antenna gain of 1.9 dBi and 3.3 dBi, respectively.
16 Submit Document Feedback
reference design with T = 25 °C, V
c
unless otherwise noted.
DDS
TEST CONDITIONS
+10 dBm setting
+5 dBm setting
Product Folder Links:
= 3.0 V, f = 2440 MHz with
DDS RF
Copyright © 2022 Texas Instruments Incorporated
CC2652PSIP
www.ti.com
MIN TYP MAX UNIT
10.5 dBm
5 dB
5 dBm
26 dB
< -36 dBm
< -54 dBm
< -55 dBm
-41 dBm
< -42 dBm
< -42 dBm
< –36 dBm
< –54 dBm
< –55 dBm
< –42 dBm
< -42 dBm
< -42 dBm
