Table 10-1 provides the bill of materials for a typical application using the CC2652PSIP module in
For full operation reference design, see the
PART
QTY
REFERENCE
1 ANT1
1 C1
1 C2
1 P1
1 U49 CC2652PSIP

10.2 Device Connection and Layout Fundamentals

10.2.1 Reset
In order to meet the module power-on-reset requirements, an external 0.1 µF capacitor is required on the
nRESET pin during power ON. In addition, VDDS (Pin 46) and VDDS_PU (Pin 47) should be connected
together. If the reset signal is not based upon a power-on-reset and is derived from an external MCU, then the
external capacitor will not be needed and VDDS_PU (Pin 47) should be No Connect (NC). Please refer to
10-1 for the recommended circuit implementation and
10.2.2 Unused Pins
All unused pins can be left unconnected without the concern of having leakage current. Please refer to
7.3 for more details.

10.3 PCB Layout Guidelines

This section details the PCB guidelines to speed up the PCB design using the CC2652PSIP module. The
integrator of the CC2652PSIP modules must comply with the PCB layout recommendations described in
the following subsections to minimize the risk with regulatory certifications for the FCC, IC/ISED, ETSI/CE.
Moreover, TI recommends customers to follow the guidelines described in this section to achieve similar
performance to that obtained with the TI reference design.
10.3.1 General Layout Recommendations
Ensure that the following general layout recommendations are followed:
• Have a solid ground plane and ground vias under the module for stable system and thermal dissipation.
• Do not run signal traces underneath the module on a layer where the module is mounted.
Copyright © 2022 Texas Instruments Incorporated
LP-CC2652PSIP Design Files
Table 10-1. Bill of Materials
VALUE MANUFACTURER
2.4 GHz Ant Texas Instruments
0.1 µF Murata
15 pF Murata
U.FL Hirose
Texas Instruments
Product Folder Links:
SWRS263A – FEBRUARY 2021 – REVISED JUNE 2022
PART NUMBER
N/A
GRT033C81E104KE01D
GRM0332C1H150JA01D
U.FL-R-SMT-1(01)
CC2652PSIPMOT
Table 10-1 for the recommended 0.1 µF capacitor.
CC2652PSIP
CC2652PSIP
Figure 10-1.
DESCRIPTION
Refer to 2.4-GHz Inverted F
Antenna for details of the
antenna implementation and PCB
requirements.
Capacitor, ceramic, 0.1 µF, 25 V,
±10%, X6S, 0201
Capacitor, ceramic, 1 pF, 50 V, ±5%,
C0G/NP0, 0201
U.FL (UMCC) connector receptacle,
male pin 50 Ω, surface mount solder
SimpleLink™ multiprotocol 2.4-GHz
wireless MCU with integrated power
amplifier
