8.16.4 RX Performance
-90
-91
-92
-93
-94
-95
-96
-97
-98
-99
-100
2.4 2.408 2.416 2.424
Figure 8-14. Sensitivity vs. Frequency
(BLE 1 Mbps)
-90
-91
-92
-93
-94
-95
-96
-97
-98
-99
-100
-40 -30 -20 -10 0 10
Figure 8-16. Sensitivity vs. Temperature
(BLE 1 Mbps, 2.44 GHz)
-92
-93
-94
-95
-96
-97
-98
-99
-100
-101
-102
1.8 2 2.2 2.4
Figure 8-18. Sensitivity vs. Supply Voltage
(VDDS) (BLE 1 Mbps, 2.44 GHz)
