STC Easy2Build Easy-Grow 8' x 8' Assembly Instructions Manual page 22

Slide pro les L06J into L06A and L06K using connectors S28. S28 connectors do
3.2A
not snap into place.
S28
L06K
Secure each connector
3.2C
with S02 screws.
S17L
S02
Pro le
Attach pro les L02B and L06K to pro le L04A. Slide long sides of connectors S01 into channels of
3.3A
pro le L04A, lining up last hole in S01 with holes in pro le L04A. Attach pro les L06A and L02A to
pro le L04A. Slides long side of connectors S01 into channels of pro les L04A, lining up last hole of
S01 with holes in L04A.
L02B
L06K
L04A
NOTE: ALL VIEWS ARE FROM INSIDE.
www.stcny.com
L06J
S28
L06A
S17R
S02
Connector
QTY
#L06J 1
L06A
S28
3.2B Place connectors S17L and S17R
on corners matching up bottom
two holes with holes in pro les
L06A, L06J and L06K as shown.
S17L
L06K
QTY
#S28 2
3.3B Secure with S02 screws.
L02A
L04A
20 of 55
S17L
S17R
L06A
#S17L
2
L06K
L02B
L04A
S02
Pro le
QTY
#L04A 2
L06J
S17R
L06K
L06A
#S17R
2
L06A
L02A
L04A
S02
Screw
QTY
#S02 4
