STC Easy2Build Easy-Grow 8' x 8' Assembly Instructions Manual page 27

3.9A
As you slide bottom pro les L01L and L01K half way into place, carefully line up S01
connectors with channels on pro les L06K and L06A and S04 and S05 connectors
with pro les L02B and L02A. Continue sliding, making sure panels Y6 and Y5 t
into V-channels. Snap connectors S04 and S05 securely into pro les.
Y6
L06K
L02B
S04 S01
L01K
!
There is only one way to properly fasten connectors into pro les. Line up parts
rst to ensure correct placement. Slide connectors until they CLICK securely into
pro le. Use WD40 or liquid soap if pieces do not easily slide together. Wear gloves.
3.9B
Secure S01 connector to pro les L06A and L06K with S02 screws.
www.stcny.com
L06A
S01
L01L
L06A
S02
L01L
L06A
Y5
Connectors S04 and S05 CLICK into place.
L02A
L06A
S05
NOTE: ALL VIEWS ARE FROM INSIDE.
25 of 55
S01
L01L
L01L
S05
Screw
S05
QTY
#S02 2
