STC Easy2Build Easy-Grow 8' x 8' Assembly Instructions Manual page 15

Slide connectors S09 and S10 half way into pro les
1.11B
L02A and L02B. Continue sliding together
making sure panels Y17 and Y18 t into
V-channels of pro les L02I and L02J.
Connectors click securely into pro les.
Connectors S09 and S10 CLICK into place.
!
There is only one way to properly fasten connectors into pro les. Line up parts
rst to ensure correct placement. Slide connectors until they CLICK securely into
pro le. Use WD40 or liquid soap if pieces do not easily slide together. Wear gloves.
1.12A
Place connectors S11 onto
pro les L02I and L03C, L02J and L03L
and L02J and L03D matching up all holes.
S11
1.12B
Screw S02 screws partially into
bottom two holes. Do not tighten.
NOTE: ALL VIEWS ARE FROM INSIDE.
www.stcny.com
S09
L02B
1.12C
S02
S02
S09
Y17
Y18
Screw S02 screws into top two holes.
Tighten all screws. Repeat for both sides.
S02
13 of 55
Y17
S10
Y18
L02A
S02
Connector
S10
QTY
#S02 12
#S11 3
