STC Easy2Build Easy-Grow 8' x 8' Assembly Instructions Manual page 19

2.6A
Open door handle kit and remove parts. Slide pin S29 through handle S30,
washer S31and hole in pro le L13C into washer S31.
S29
2.6C Hook one side of spring S33 into hole on
handle S30. Hook the other side into pin
hole on pro le L13C.
S33
2.7A
Slide two hex bolts S13 into
channel of pro le L05F.
L05F
Remove protective plastic from both sides of panels Y26. Place side to face toward the sun facing down.
2.8A
Fit panels into channels of pro le L05F.
!
Remove protective plastic from EACH side of poly carbonate
panels before installing. Dispose of plastic properly. Install with
side labeled "Face this side towards the sun" FACING DOWN.
www.stcny.com
S30
S31
S31
L13C
L13C
S13
2.6B
Slide washer S32 into
groove on pin S29 to
hold securely in place.
L13C
NOTE: Connectors packaged as Door Handle Kit.
Connector
2.7B Screw two S14 hex nuts onto
bolt on each end. Do not
completely tighten.
Panel
QTY
#Y26 2
17 of 55
S32
Connector
QTY
#S29 1
#S30 1
L05F
L05F
Pro le Bolt / Nut
QTY
#L05F 1
QTY
#S31
2
#S32 1
#S33 1
S14
QTY
#S13 2
#S14 2
