5. Programming Procedure
5.3

Show Program

46
This submenu is used to display the parameters that have been defined for a
program. An example wash program containing one cycle, one wash step and a
final aspiration step will be used to demonstrate this menu.
The displayed parameter settings cannot be altered in this submenu.
SHOW
< > EXIT OK
PROG1: EXAMPLE
- + EXIT OK
STRIP MODE
EXIT OK
1: GRE96ft
EXIT OK
C1 CYCLE
- + EXIT OK
C1 P1 WASH
- + EXIT OK
POS: OVERFLOW
EXIT OK
VOLUME 300µl
EXIT OK
CHANNEL 1
EXIT OK
H-SPEED 10mm/s
EXIT OK
FL.RATE 300µl/s
EXIT OK
C1 P1 WASH
- + EXIT OK
FIN.ASPIRATE
- END OK
HYDROFLEX PLUS No. 30199906 Rev. No. 1.1
Press OK to enter the Show menu.
Select required program to show.
Press + or – to select programs from other positions.
Selected mode is displayed.
Selected plate type displayed
Cycle 1 will be shown.
Press + to show the program steps of this cycle.
Press OK to show the cycle number.
Press OK to show the parameters of the program step.
Press + to continue to the next program step;
Press "- " to return to the previous step.
Press OK to continue to the next parameter
of the selected program step.
Press OK to continue to the next parameter
of the selected program step.
Press OK to continue to the next parameter
of the selected program step.
Press OK to continue to the next parameter
of the selected program step.
Press OK to continue to the next parameter
of the selected program step.
Once all parameters of the step have been shown the selected
Program Step appears again. Press + to continue to the next
program step; Press "- " to return to the previous step.
Press OK to show the parameters of the final aspiration
step. If no final aspirate step was used, "CX CYCLEEND"
appears. Press OK to view the cycle number.
Press END to exit the Show menu. Press - to return to the
previous step.
