Axle, diameter 190 or 192 mm
Product presentation
Ref
Description
1
Flange, motor side
2
Safety splint Ø3, A2 SS
3
Clamping pin Ø12 106mm, SS
4
Aluminium axle
5
HE nut M8 A4 SS
6
HSHC screw M8 x 35 A4 SS
7
Flange, bearing side
8
Stainless steel clevis mount
The curved side on the top of the flange should be oriented towards the axle.
PROTECTION & SAFETY
COVERDECK AX-IN AXLE
Qty
1
2
1
1
4
4
1
1
CAUTION
12
2020/11 - Version: B - Code : 34561
