2.3.

Commissioning and operating instructions

Test opening and closing of the cover to check that there is no friction or catching. Noise could be an indication
that profile is badly positioned and/ or that the water level is too high.
Reminder: max 50 mm below the top of the pool wall.
Safety recommendations and advice
Do not install the profile against the liner, always allow a gap (minimum 5 mm) or protection.
3.

Installation of the duckboarding

Shape the first duckboarding module to match the curve of the coping (if necessary).
Insert or remove wedges depending on the coping height:
Coping
M20 Remove the 8 mm wedges present
M30 Check that the original 8 mm wedges are
present
M40 On the wall side, add an additional 8 mm wedge
to the original 8 mm wedge
M55 On the wall side, add an additional 23 mm
wedge to the original 8 mm wedge
High water level
Lay the first 1 m wide duckboarding module, check:
‐ that is covers the first bracket fully,
‐ that is cover half of the second bracket.
Lay the other 1 m wide coping modules, check:
‐ that the duckboarding modules come together in the middle of the bracket.
Trim the length of the duckboarding module(s) according to the diagram enclosed; shape the coping to
accommodate the duckboarding if necessary, check:
‐ that the coping modules come together in the middle of the bracket
‐ that the last duckboarding module fully covers the last bracket.
Standard water level and high water level
Adjust the gaps between the duckboarding modules so that they are equal and less than 8 mm.
Wooden duckboarding
Adjust the wooden coping modules so that the gap is always less than 8 mm.
PROTECTION & SAFETY
Wooden duckboarding PVC duckboarding
Not possible
No wedge
Add an 8 mm wedge on the wall side
Add an 23 mm wedge on the wall
side
41 2020/06 - Indice de révision : A - Code : 34560
