2.5.

Retainers for pools with step pieces (option)

If the slat apron features a section to cover submerged steps or a particular pool shape, this section will be fitted
with retainers attached under the 2
the axle, and prevent it from unrolling backwards by itself.
2.6.

PVC slats: Guide weights for overflow pools (option)

Ref
1 Slat plug
2 Guide weight
3 Overflow bracket*
4 Slat
*The bracket is supplied with the hasp fastener for the buffer
and overflow tank.
The overflow bracket (3) is a removable part, it plays a role in
safety. It must be put in place when the cover is rolled out over the pool and must be removed before opening
the cover.
The guide weight (2) is mounted on the overflow slat in the factory. Its purpose is to guide the cover apron while
it is being rolled up and rolled out.
Spacing between fasteners for overflow pools
The fasteners may be at most 1.8 m apart.
4 packets of 6 slats + slat radius 15 or fastener slats
PROTECTION & SAFETY
nd and 8th slats. These retainers block the slat apron when it is rolled around
Description
4 packets of 6 slats
Qty
1
1
1
1
4 packets of 6 slats
Slats for lateral fasteners
29 2020/06 - Indice de révision : A - Code : 34560
