3.

Civil engineering

3.1.

With masonry pit wall

Distance to beam support plate
Wall th.
Pool width
Beam
Wall height
Coping M30
Water 135
Standard separating pit wall width: Wall width = 250 mm
Minimum cover pit depth: pit depth = min 1.06 m
3.1.

With a separating pit wall

Distance to beam support plate
Partition th.
Pool width ≤ 6,09 m
Beam 133 mm
Wall height
Coping M30 M40 M55
Water 135
Standard separating pit panel width = 40 mm
Minimum cover pit depth: pit depth = min 1.06 m
Standard vertical radius: R = square corner or 150 mm
PROTECTION & SAFETY
Distance to cover flange
Distance to wall
≤ 6.09 m
133 mm
210
M40
M55
125 110
Distance to cover flange
Duckboarding
Dist to beam support
210
Dist to cover flange
125 110
Duckboarding
Distance to wall
Distance to beam support
plate
Distance to the cover flange
Distance to duct
680
Corner 90°
750
plate
130
9
Return fitting Main drain
Pool width
830 950
880 1000
900 1020
130 180
305 355
Return fitting
Pool width
830 830 950
90° R=150 R=150
900 900 1020
180 275 330
