NOTA BENE: The ends of travel can be deleted from memory in the event of a power outage:
‐ While the cover is in motion, either opening or closing.
If the cover is partially open or partially closed.
‐
In that event, simply reprogram the ends of travel as described previously.
Once the wiring has been checked and the ends of travel have been verified, pour the two-component gel
(self-levelling) into the connection box until the terminal block and wires submerged. Close the connection
box.
6.

Wiring diagram

Light switch
PROTECTION & SAFETY
Turn the key and hold it in position until the cover apron is round the axle. Validate
the pool open position by pressing
LED is lit up.
Turn the key to close the pool. Hold the key in position until the motor stops.
Turn the key in the other direction, giving it a twist. The 2
rolls up around the axle. When the LED goes out, programming is complete.
Open
Close
Level
. The leftmost LED goes out and the second
AC closed
AC closing.
opening
Motor
Motor
22
nd LED blinks. The cover
Light switch
AC open
Shielding
