swimming in the pool.
Release the key once the cover stops moving.
‐
Remove the key from the lock and store it in a location out of the reach of children.
‐
4.
Safety fasteners
4.1.
Engaging the cover in the safety fasteners
Once the cover is fully rolled out over the pool, press the button A and push the slide bar up, then push it down
through the strap ring. Push the slide bar down fully to ensure that it is locked.
Closed position
4.2.
Releasing the cover from the safety fasteners
Press the button A and push the slide bar up to release the strap ring.
5.
Water level
In the case of a submerged automatic cover, the use of a level controller and an overflow are mandatory.
It is essential to check the water level in the pool before operating the automatic cover, bearing in mind that a
gap of 30 mm is required between the water level and the beam to allow the cover to move freely.
A water level that is too high, consequence of a blocked/ lack of overflow, can cause the cover apron to become
blocked against the beam and stop it from moving properly, this could lead to significant damage to the cover
slats and mechanical components.
Never put the cover in motion if the water level is too low, this could cause the cover to become blocked on and
then rub against the top of the pit wall, and any abutments or hand-rails.
Lastly, a water level that is too high or too low could modify the open and closed parameters saved when the
ends of travel of the reduction motor were initially programmed.
NOTA BENE :
The standard NF P90-308, dealing with the design and safety of automatic pool covers, explicitly
states that pools fitted with an automatic cover must be equipped with a pit wall (masonry or prefab), that
separates the automatic cover rolling pit from the rest of the pool.
PROTECTION & SAFETY
The use of safety straps is required by French regulations.
Do not forget to release the straps before rolling the cover up.
Significant damage could result from the failure to do so.
Open position
IMPORTANT
44
Blocked open position
2020/06 - Indice de révision : A - Code : 34560
