1.1

Installation Warnings

This is a three-phase four-wire on-line uninterruptible power supply (hereafter referred
to as 'UPS'). It can be used for commercial and industrial applications.
Install the UPS in a well-ventilated indoor area, away from excess moisture, heat, dust,
tions, please refer to
Leave adequate space around all sides of the UPS for proper ventilation and mainte-
nance. Please refer to
Only authorized Delta engineers or service personnel can perform installation and
maintenance. If you want to install the UPS by yourself, please install it under the su-
pervision of authorized Delta engineers or service personnel.
Follow the IEC 60364-4-42 standard to install the UPS.
1.2

Connection Warnings

Before applying electrical power to the UPS, make sure the UPS is grounded to avoid a
possible risk of current leakage.
You can parallel a maximum of eight UPS units.
The UPS must be connected with an external battery cabinet (user-supplied, handled
The installation of protective devices is highly recommended when the UPS is connect-
ed to power sources and critical loads.
The protective devices connected to the UPS must be installed near the UPS and easily
accessible for operation.
Protective Devices:
1. For single input, you must install (1) a protective device between the main AC source
and the UPS and (2) a protective device between the connected critical loads and
the UPS.
2. For dual input, you must install (1) a protective device between the main AC source
and the UPS, (2) a protective device between the bypass source and the UPS and (3)
a protective device between the connected critical loads and the UPS.
3. For grounding information, please refer to
Modulon DPH Series
for relevant information.
1-2
.
.
and
-
-
.
