Delta Modulon DPH Series User Manual page 169

Button
Function
No. Icon/ Text
(Yes or
No)
EVENT LOG
6
2
WARNING
2
WARNING
10:15
7
Sep 25,2018
On-Line
ECO
Frequency Conversion
Green
8
Energy Recycle
Bypass
Battery
Standby
Softstart
9
Power Flow
Text/ Symbol
Digital Display
Display (Yes or
(Yes or No) No)
7-9
7 LCD Display & Settings
Description
1. Event log shortcut icon (
Tap the icon to check all the event
logs.
2. When the warning icon (
it indicates that there is no warning.
1. Warning event shortcut icon (
2. Buzzer icon (
3. When the warning icon (
it indicates that there is a warning. At
this time, the buzzer will sound and
the buzzer icon (
light up. The numerical value at the
upper right of the red warning icon
indicates the total number of warning
events. By tapping the buzzer icon
( ), the buzzer will be muted.
At this time, the buzzer disabled icon
( ) will appear. If there is any
warning event afterwards, the buzzer
will sound and the buzzer icon (
will appear and light up again.
Indicates the time and date.
Indicates the UPS's current operation
status (the actual display depends on
the actual operation status).
Tap the icon to check the operation
mode and status of the UPS. For more
information, please refer to
.
).
EVENT LOG
) is blue,
2
).
WARNING
).
) is red,
) will appear and
)
