Feature Summary; How It Works - DirectOut Technologies EXBOX.SG User Manual

Feature Summary

MADI Ports
Network
Number of channels
Network Standards
Clock Sources
Remote
MADI Formats
Sample Rates
Signal Routing
Power Supply
* The SC I/O may be ordered as single-mode upon request.

How it works

Each MADI port and the Soundgrid input can be selected as source for any output.
Device functions such as signal routing, MADI output format and clock settings are
controlled via globcon.
The audio network is controlled via a Soundgrid host application (e.g. SG Studio or
SG QRec).
SFP
BNC
SC
Soundgrid
To setup globcon control please refer to "globcon control" on page 21.
EXBOX.SG Manual - Version 1.0
1 x SC multi-mode connectors *
1 x SFP (empty cage without module)
1 x coaxial BNC connectors
3 x RJ45 Socket (1 Gbit/s),
1 x RJ45 (1 Gbit/s, PoE)
128 @ 1 FS, 64 @ 2 FS
Soundgrid
Sync over Ethernet (SoE), MADI, WCK, INT
globcon control via MIDI tunnel
Soundgrid application (e.g. SG Studio, SG QRec)
56/57/64 channel, 48k/96k Frame, S/MUX 2/4
44.1, 48, 88.2, 96 kHz +/-12.5%
Port based routing matrix
external,
2 x Hirose connector (9-24 V)
1 x PoE (Power over Ethernet,
Routing
EXBOX.SG
IEEE 802.3af)
SFP
BNC
SC
Soundgrid
