Accessory

Two different optical SFP transceiver for MADI transmission are available from
DirectOut GmbH:
• Multimode SFP transceiver with LC connectors (No: DOICT0129)
• Singlemode SFP transceiver with LC connectors (No: DOICT0130)
Specification of the optical SFP modules:
SFP
Wavelength TX
nominal
Wavelenght RX
nominal
Distance
Powerbudget (dB)
Protocols
Bandwidth from
Bandwidth
Laser
Receiver Type
Connector
Wavelength TX min
Wavelength TX max
Wavelength RX min
Wavelength RX max
Transmit min
Transmit max
Receive min
Receive max
(Receiver overload)
Temperature (min)
Temperature (max)
Type of DDM/DOM
Extinction Ratio
EXBOX.SG Manual - Version 1.0
Multimode
1310 nm
1310 nm
2 km
> 11 dB
Fast Ethernet OC3/STM1
100 Mbit/s
155 Mbit/s
FP
PIN
LC
1260 nm
1360 nm
1260 nm
1620 nm
- 19.00 dBm
- 14.00 dBm
- 30 dBm
- 5.00 dBm
0° Celsius
70° Celsius
internal
8.20 dB
Singlemode
1310 nm
1310 nm
10 km
> 12 dB
Gigabit Ethernet, Gigabit
Fibre Channel
1.050 Gbit/s
1.250 Gbit/s
FP
PIN
LC
1260 nm
1360 nm
1260 nm
1600 nm
- 9.00 dBm
- 3.00 dBm
- 21.00 dBm
- 3.00 dBm
0° Celsius
70° Celsius
internal
9 dB
