The device control panel offers:
Internal* Clock source is provided by the Soundgrid module of the
device and device acts as SoE clock master. Other devices
in the Soundgrid network will lock to it.
Sync over Clock source is provided by Soundgrid network. Device acts
Ethernet** as SoE slave.
Digital*** Clock source is provided by external sources of EXBOX.
SG (MADI input, Word Clock input) or by the internal clock
generator.
* available when device is SoE clock master
** available when device is SoE clock slave
*** clock source is set in globcon
The globcon 'Sync' tab to adjust clock source:
NOT E
This setting is relevant and accessible only when the device control panel is set to
'DIGITAL'.
