Feature Summary

MADI Ports
Network
Number of streams
Number of channels
Network Standards
Modes
Clock Sources
Remote
MADI Formats
Sample Rates
Signal Routing
Signal Processing
Signal Redundancy
Power Supply
* The SC I/O may be ordered as clocking
-mode upon request.

Applications

EXBOX.RAV can be used as an easy to use frontend for bidirectional signal
exchange between RAVENNA and MADI environments.
Typical applications include:
• Integration of MADI in RAVENNA setups
• Signal Routing via NMOS
in broadcast environments
• Signal switch for redundant playback setups
EXBOX.RAV Manual - Version 1.0
1 x SC multi-mode connectors *
1 x SFP (empty cage without module)
1 x coaxial BNC connectors
3 x RJ45 Socket (1 Gbit/s),
1 x RJ45 (1 Gbit/s, PoE)
32
64 @ 1 FS, 32 @ 2 FS, 16 @ 4 FS
RAVENNA, AES67 , ST 2110-30 / -31
Switched or Redundancy as per ST 2022-7
PTP , MADI, WCK, INT
Browser GUI, globcon control,
NMOS IS-04 / IS-05
56/64 channel, 48k/96k Frame, S/MUX 2/4
44.1, 48, 88.2, 96, 176.4, 192 kHz +/-12.5%
Channel based routing matrix
FastSRC™ at RAVENNA I/O
Enhanced Automatic Redundancy Switching (EARS™)
external,
2 x Hirose connector (9-24 V)
1 x PoE (Power over Ethernet, IEEE 802.3af)
