- Page 1 SPLIT.CONVERTER User's Manual Version 2.0...
- Page 2 DirectOut GmbH cannot be held responsible for any misleading or incorrect information provided throughout this manual. DirectOut GmbH reserves the right to change specifications at any time without notice. DirectOut Technologies® is a registered trademark of the DirectOut GmbH. © DirectOut GmbH, 2017 page 2 of 24...
-
Page 3: Table Of Contents
CHAPTER 4: Operation Global Control ....................16 Connecting MADI ..................17 Signal Routing ..................... 18 CHAPTER 5: Troubleshooting and Maintenance Troubleshooting ................... 20 Maintenance ....................20 CHAPTER 6: Technical Data Index SPLIT.CONVERTER Manual - Version 2.0 page 3 of 24... - Page 4 This page is left blank intentionally. page 4 of 24 SPLIT.CONVERTER Manual - Version 2.0...
-
Page 5: About This Manual
WAR NI N GS! alert you when an action should always be observed. This document relates to: • SPLIT.CONVERTER (BNC / SC) • SPLIT.CONVERTER optical (SC / SC) SPLIT.CONVERTER Manual - Version 2.0 page 5 of 24... -
Page 6: Chapter 1: Overview Introduction
CHAPTER 1: Overview CHAPTER 1: Overview Introduction The SPLIT.CONVERTER is a combined MADI format converter and signal splitter with four MADI ports. With one RU height, two redundant power supplies and a straightforward source selector it allows for instantaneous conversion or distribution of MADI signals. -
Page 7: Applications
CHAPTER 1: Overview Applications SPLIT.CONVERTER can be used to convert MADI signals in “mixed environments” or for distribution of MADI signals. Typical applications include: • Switching converter units between control rooms • Redundancy splitting/switching (manually) during recording or live sound applications. -
Page 8: Chapter 2: Legal Issues & Facts
We would like to remind you to please check carefully whether the failure is caused by erroneous configuration, operation or connection before sending parts for repair. page 8 of 24 SPLIT.CONVERTER Manual - Version 2.0... -
Page 9: First Aid (In Case Of Electric Shock)
Check their pulse and reanimate if their respiration is poor. Lay the body down and turn it to one side. Call for a doctor immediately. • Having sustained an electric shock, always consult a doctor. SPLIT.CONVERTER Manual - Version 2.0 page 9 of 24... -
Page 10: Updates
DirectOut website: www.directout.eu. Intended Operation The SPLIT.CONVERTER is designed for the conversion and distribution of MADI signals (AES10) and other signals which meet the electrical specifications of MADI. WARN ING ! No compensation can be claimed for damages caused by operation of this unit other than for the intended use described above. -
Page 11: Conformity & Certificates
09648 Mittweida Germany Only stamped parcels will be accepted! WEEE-Reg.-No. DE 64879540 Contact DirectOut GmbH Leipziger Str. 32, 09648 Mittweida, Germany Phone: +49 (0)3727 5665-100 Fax: +49 (0)3727 5665-101 Mail: sales@directout.eu www.directout.eu SPLIT.CONVERTER Manual - Version 2.0 page 11 of 24... -
Page 12: Contents
CHAPTER 2: Legal issues & facts Contents The contents of your SPLIT.CONVERTER package should include: • 1 x SPLIT.CONVERTER (19’’, 1 RU) • 2 x power chord • 2 x fixing unit for power plug • 1 x User's Manual Two different MADI I/O confi... -
Page 13: Chapter 3: Installation
(Version BNC / SC) (Version SC / SC) N OT E Retain the protective cap if the optical port is unused. This will protect against soiling which can lead to malfunction. SPLIT.CONVERTER Manual - Version 2.0 page 13 of 24... - Page 14 Turn on the power switch and check the status of PSUs on the front panel: T I P Keep any packaging in order to protect the device should it need to be dispatched for service. page 14 of 24 SPLIT.CONVERTER Manual - Version 2.0...
- Page 15 CHAPTER 3: Installation This page is left blank intentionally. SPLIT.CONVERTER Manual - Version 2.0 page 15 of 24...
-
Page 16: Chapter 4: Operation
Note that an unlit LED does not guarantee that the device is free of voltage. To ensure that the device is completely disconnected from mains voltage, the power chords must be disconnected. page 16 of 24 SPLIT.CONVERTER Manual - Version 2.0... -
Page 17: Connecting Madi
MADI input (64 ch), connect MADI input signal here N OT E SC Ports may be equipped with multi-mode or single-mode modules. Mixed combinations offer the comfortable conversion between multi-mode and single- mode I/Os. See „Examples“ on page 19. SPLIT.CONVERTER Manual - Version 2.0 page 17 of 24... -
Page 18: Signal Routing
CHAPTER 4: Operation Signal Routing All four MADI input signals are fed to a routing matrix where they can be distributed to any output. This allows the SPLIT.CONVERTER to convert and distribute MADI signals: Encoder PORT A (ABCD) Turn the rotary control to the desired position to select the desired input source for output A. - Page 19 Signal distribution of one MADI signal (4 x optical, '1:4') Signal A Signal A Signal A Signal A Format conversion of four MADI signals (single mode <> multi-mode) Signal C Signal D Signal A Signal B SPLIT.CONVERTER Manual - Version 2.0 page 19 of 24...
-
Page 20: Chapter 5: Troubleshooting And Maintenance
To clean the device, use a soft, dry cloth. To protect the surface, avoid using cleaning agents. NOT E The device should be disconnected from the power supply during the cleaning process. page 20 of 24 SPLIT.CONVERTER Manual - Version 2.0... -
Page 21: Chapter 6: Technical Data
• Multi mode 62.5/125 µm or 50/125 µm • optional: single mode 9/125 µm Sample Rate • 32 kHz to 192 kHz MADI Format (I/O) • 48k Frame, 96k Frame • 56 channel, 64 channel • S/MUX 2/4 SPLIT.CONVERTER Manual - Version 2.0 page 21 of 24... -
Page 22: Index
Fuses ............21 Intended Operation ........10 Sample Rate ..........21 Signal Routing Examples ..........19 Single-/Multi-mode ........12 Support ............ 20 Technical Data .......... 21 Troubleshooting ........20 Updates ........... 10 page 22 of 24 SPLIT.CONVERTER Manual - Version 2.0... - Page 23 Notes SPLIT.CONVERTER Manual - Version 2.0 page 23 of 24...
- Page 24 DirectOut GmbH Leipziger Strasse 32 T: +49-3727-5665-100 09648 Mittweida F: +49-3727-5665-101 Germany www.directout.eu...
