CHAPTER 1: Overview
page 6 of 7
feature summary
MAdi Ports
MAdi formats
sample Rates
Clock inputs
operating
Modes
Remote
operation:
Power supply
MADI.SRC Manual - Version 1.4
DirectOut Technologies
1 x Optical SC multi/single mode
connector (input / output)
1 x Coaxial BNC connector (input / output, 75 Ω)
56/64 channel, 48k/96k Frame, S/MUX 2/4
44.1, 48, 88.2, 96, 176.4, 192 kHz +/-12.5%
1 x word clock coaxial BNC
75 Ω termination switchable
This input also accepts an
AES3 frame (AES11)
1 x Video
coaxial BNC
75 Ω termination switchable
Black Burst (PAL, NTSC)
Normal Mode: one input is active;
the outputs are fed in parallel.
Split Mode:
inputs and outputs
are combined.
USB 2.0 port for firmware updates
This device is equipped with two wide
range power supplies (84 V to 264 V AC
/ 47 Hz to 63 Hz / safety class 1).
®
© 2014 DirectOut GmbH
