CHAPTER 5: Controlling
Signal Routing - Soundgrid
To setup your signal routing between Soundgrid devices open the tab ‚PATCH' and
switch to the routing matrix ‚DEVICE TO DEVICE. With EXBOX.SG connected you
should see 128 channels of Soundgrid @ 1FS (or 64 channels @ 2 FS).
Signal Routing - MADI
The signal routing between the three MADI IOs and Soundgrid is managed in
globcon. Entire ports can be patched only.
page 34 of 54
EXBOX.SG Manual - Version 1.0
