Feature Summary - DirectOut Technologies PRODIGY.MC Hardware Manual

Feature Summary

Audio Network
Modules *
MADI Modules *
Converter Modules*
Headphones
Word Clock (I/O):
Supported Audio
Network Standards
(depending on module)
MADI Formats
Sample Rates
Management Port
Device Control
GPIO
USB Port
Power Supply
* see „Slots - Connecting Audio" on page 29 for a comprehensive description
of the different modules available.
Prodigy.MC Hardware Guide - Version 1.0
1 slot (1 x SFP , 2 x RJ45 Socket) - configure to order:
- Dante (64 channels)
- RAVENNA (128 channels)
- SoundGrid (128 channels)
2 slots - :
- SFP (empty cage without module)
- SC-Socket multi/single-mode
- coaxial BNC, 75 Ω
8 slots - individually configurable - 8 channels each:
- Analog I/O - Line In / Out
- Mic I/O - Mic In / Line Out
- Digital I/O - AES3 In / Out
1 x 6.3 mm jack
1 x 3.5 mm jack
2 x coaxial BNC
(75 Ω termination switchable)
Dante / AES67
RAVENNA / AES67 , ST 2110-30/31, ST 2022-7
(Seamless Protection Switching)
SoundGrid
56/64 channel, 48k/96k Frame, S/MUX
44.1, 48, 88.2, 96, 176.4, 192 kHz +/-12.5%
1 x RJ45 Socket (Gigabit-Ethernet)
remote: via globcon or browser
local: via touch-display
1 x DSUB-9 (2 x GPI, 2 x GPO, MOSFET switches)
USB 2.0 port for legacy control of ANDIAMO devices
This device is equipped with two wide range power
supplies (84 V to 264 V AC / 47 Hz to 63 Hz / safety
class 1)
CHAPTER 1: Overview
page 7 of 64
