Appendix A - Wiring Sketches
Hirose HR10 (DC PSU)
1
2
4
3
NOT E
To ensure proper operation all pins should be connected.
NOT E
Ground is connected with the chassis of the plug (safety class 1).
Appendix A - Wiring Sketches
Pin
Signal
1
DC +
2
DC +
3
DC -
4
DC -
EXBOX.SG Manual - Version 1.0
