CHAPTER 7: Technical Data
Dimensions
• Width 140 mm
• Height 42 mm
• Depth 146 mm
Weight
• 0.7 kg
Power Consumption
• 9 W (typical)
Power Supply
• 2 x Hirose socket (HR10)
• 9 V - 24 V DC (external)
WARN ING !
The connected power supply must provide a current limiting to a maximum of 2.5 A.
Environmental Conditions
• Operating temperature +5°C up to +45°C
• Relative humidity: 10% - 80%, non condensing
MADI Ports SC optical
• SC socket FDDI (input / output)
• ISO/IEC 9314-3
• Wave length 1310 nm
• Multi-Mode 62.5/125 or 50/125
MADI Ports BNC coaxial
• BNC socket (input / output)
• Impedance: 75 Ω
• 0.3 V up to 0.6 V (peak to peak)
MADI Ports SFP
• empty cage without module
Sample Rate (for MADI and Word Clock)
• 30 - 50 kHz @ 1 FS
• 60 - 100 kHz @ 2 FS
CHAPTER 7: Technical Data
EXBOX.SG Manual - Version 1.0
