DirectOut Technologies EXBOX.SG User Manual page 17

6. Using the power cord of the external power supply provided, connect the
device to a matching power supply and connect the output of the power
supply to the Hirose connectors at the rear panel.
This device may operate with only one power supply. To provide power
supply redundancy, it is recommended to connect both PSU 1 and PSU 2
to independent power supplies with separate fuses.
N OT E
The shipment includes one external power supply unit. Additional power
supply units are available from your local DirectOut representative.
WAR NI N G!
The external power supply must be connected to the mains using the three-
cord power leads supplied with the device. Only supply the voltages and signals
indicated (9 - 24 V DC) to the device.
WAR NI N G!
The connected power supply must provide a current limiting to a maximum of 2.5 A.
EXBOX.SG Manual - Version 1.0
Chapter 3: Installation
page 17 of 54
