Specifications

Hardware
Discrete Alarm
0-4 (NGBSM G2 only)
Inputs:
Control Relays: 2-4 (NGBSM G2 only)
Dimensions:
1.720" H x 17.026" W x 6.916"
D
Mounting: 19" or 23" Rack Mount
Weight: 2.66 lbs (1.21 kg)
Power Input: -48 VDC (-36 to -60 VDC)
(Single or Dual)
1 Current Draw: 35 mA
GMT Fuse: 3/4 Amp GMT Fuse
Visual 1-5 Front Panel LEDs
Interfaces:
Software
Downloadable Yes
Firmware:
Built-in Web Yes
Interface:
Browser IE9, IE10, Firefox, Chrome
Support:
Protocols: SNMPv1, SNMPv2c, SNMPv3,
DCPx, TELNET, HTTP, HTTPS,
Email
Note:
1 Current measured at rated voltage with all controls latched and all alarms triggered.
2 Valid if hardware option is included.
* This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
2 Hardware Interfaces:
Operating Temp:
Industrial Operating Temp:
Storage Temp:
Operating Humidity:
MTBF:
RoHS:
Ping Targets:
OS Support:
SNMP Support:
1 RJ45 10/100BaseT full-duplex
Ethernet port
1 USB rear-panel craft port
1 DB9 for CAN serial interface
(adjustable baud, NGBSM only)
1 RJ-45 for CAN bus interface
(G2 only, 500kb/s)
1 built-in termination resistor for
CANBUS, with shunt (G2 only)
32° to 140° F (0° - 60° C)
-22° to 158° F (-30° to 70° C)
-40° to 185° F (-40° to 85° C)
0% - 95% non-condensing
60 Years
RoHS 5/6 Approved
32
XP, Vista, 7,8,10 (32 or 64 bit)
V1, V2c, V3
