Specifications

Dimensions:
Weight:
Mounting:
Power Input:
Current Draw:
Fuse:
Interfaces:
Operating Temperature:
Operating Humdity:
4

Operation

The DAC-P communicates with its alarm collection remotes through dial-up connection. The DAC-P has four DB9 RS-232
serial ports for connecting to up to four modems and four phone lines. The dial-up connection between the DAC-P and its
remotes is two-way; either the DAC-P can initiate a call to poll a remote, or a remote can initiate a call to report an alarm.
The remote will call the DAC-P if:
• Any alarm occurs. (All alarm events are considered equally severe.)
The DAC-P will call the remote if:
• The alive/full update time expires without a call from the remote. The default alive/full update time is 24 hours. The DAC-
P will reset the alive/full update clock if the remote calls to report an alarm.
• The DAC-P receives a control relay command for the remote unit.
• The DAC-P receives a dial command for the remote unit.
• The DAC-P receives a reboot command for the remote unit.
• A DAC-P user chooses the Dial RTU or Reboot RTU command from the terminal interface.
1¾"H x 17"W x 12"D (4.45 cm x 43.18 cm x 30.48 cm)
4 lbs. 3 oz. (1.9 kg)
19" or 23" rack
–48 VDC
200mA
1 Amp GMT
4 DB9 RS-232 serial ports
4 DB9 RS-485 TABS ports
1 RJ45 10baseT Ethernet port
1 RJ11 POTS jack
1 DB9 craft port
32°–140° F (0°–60° C)
0%–95% noncondensing
