NetGuardian BSM Front and Back Panel
LED
Status
CAN
RS232
NetGuardian BSM Front Panel
NetGuardian BSM Back Panel
Status
Flashing Green
Application Running
Flashing Red
Bootloader Running
Tx
Transmit to CAN Network
Rx
Receive from CAN Network
Tx
Transmit to NetGuardian
Rx
Receive from NetGuardian
NetGuardian BSM Top Panel LEDs
