NetGuardian BSM G2 Front and Back Panel
Front Panel
LED
Status
CAN-BUS
Relay (1 or 2)
NetGuardian BSM G2 Front Panel
NetGuardian BSM G2 Back Panel
Status
Flashing Green Application Running
Flashing Red
Bootloader Running
Flashing Green Transmit to CAN Network
Flashing Red
Receive from CAN Network
Solid Green
Relay is latched
Off
Relay is released
Description
