DPS Telecom NetGuardian BSM User Manual page 61

Display Point
1-16
17-32
Display 25
33-48
49-64
Display Point
1-16
17-32
Display 26
33-48
49-64
Display Point
Display 27 1-64
Display Point
1-8
9-16
17-24
Display 28
25-32
33-40
41-48
49-64
Display Point
1
2
3
4-32
33
34
35
36
37
38
39
40
41
42
Display 29
43
44
45
46
47
48
9
50
51
52
53
54
55
56
58-64
Description
Battery #4 Remaining Capacity (Ahr)
Battery #4 Average Cell Temperature (°C/ °F)
Battery #4 Nominal Float Voltage (VDC)
Battery #4 Estimated Runtime (minutes)
Description
Battery #4 Design Max Capacity (Ahr)
Battery #4 State of Health (%)
Battery #4 Number of Complete Discharge Cycles
Battery #4 Usable Capacity (Ahr)
Description
Battery #5 Serial Number
Description
Battery #5 Software Version
Battery #5 Software Revision
Battery #5 Hardware Version
Battery #5 Type ID
Battery #5 Type Switch Setting
Battery #5 Firmware/Hardware Match
Undefined
Description
Undefined
Battery #5 Not Detected
Battery #5 Sent to Sleep
Undefined
Battery #5 Operation Mode: Initializing
Battery #5 Operation Mode: Wake-Up
Battery #5 Operation Mode: Validating
Battery #5 Operation Mode: Post
Battery #5 Operation Mode: Normal
Battery #5 Operation Mode: Lock-Out
Battery #5 In Lock-Out
Battery #5 Charge Mode: Initializing
Battery #5 Charge Mode: Float
Battery #5 Charge Mode: Charge
Battery #5 Charge Mode: Discharge
Battery #5 Charge Mode: Charge Complete
Battery #5 Current: Warning
Battery #5 Current: Alarm
Battery #5 Current: Lock-Out
Battery #5 Temperature: Warning
Battery #5 Temperature: Alarm
Battery #5 Temperature: Lock-Out
Battery #5 Low Voltage: Warning
Battery #5 Low Voltage: Alarm
Battery #5 Low Voltage: Lock-Out
Battery #5 High Voltage: Warning
Battery #5 High Voltage: Alarm
Battery #5 High Voltage: Lock-Out
Undefined
57
