Figure 1 Uneven Density
Image Quality
IQ7, IQ8

IQ8 Background RAP

Uniform toner contamination appears in most or all non-image areas of the printed sheet
ure 1).
Initial Actions
• Check that media type settings are correct.
• Check that the paper meets specifications. Refer to Section 6 for product specifications.
• Check the supplies life of the Print Cartridge, refer to
Replace the Print Cartridge if it has reached end of life.
Procedure
• Switch off the power.
• Clean the contacts on the Print Cartridge and the LVPS / HVPS PWB.
• Switch on the power and make a test print.
The test print looks OK.
Y N
Replace the LVPS / HVPS PWB;
Go to SCP 04 Final Actions.
June 2014
3-8
GP 2 Machine Status and Reports.
(REP 1.5), PL 3.1.
Figure 1 Background
Xerox® Phaser® 3020 Printer Service Manual
(Fig-
