6.1 LSU
1
MAIN PWB
PL 1.1
2
3
4
5
6
BSDs
C D
J6 P6 +24 VDC
1
+24 VDC
DC COM
2
DC COM
MOTOR ENABLED
3
READY
4
CLOCK
5
POWER
8
LSU 1
9
LSU ON
10
DC COM
11
DC COM
V1 DN
12
V1 DP
13
DC COM
14
DC COM
SYNC SIGNAL
15
3.3 VDC
16
+3.3 VDC
E F
LSU
PL 3.1
5
+24 VDC
4
DC COM
3
6
2
1
9
8
7
6
DC COM
5
4
3
DC COM
2
1
+3.3 VDC
