Port Function Configuration Packet
Packet ID
Length
Field #
Bytes
Data
Offset
Type
1
0
u8
2
1
u8
3
2
u8
4
3
u8
5
4
u8
6
5
u8
7
6
u8
8
7
u8
9
8
u8
10
9
Table 100: Port function configuration packet
10.11.7.1
Ports
Port
1
Port 1 function (default TCP 16718)
2
Port 2 function (default TCP 16719)
3
Port 3 function (default TCP 16720)
4
Port 4 function (default TCP 16721)
Table 101: Ports mapping for the two models of GNSS Compass
All manuals and user guides at all-guides.com
Port Function Configuration Packet
Size
1
1
1
1
1
1
1
1
1
4
Ethernet Model
GNSS Compass Reference Manual
Page 80 of 85
Version 1.1
13/01/2021
188
13
Description
Permanent
Port 1 transmit function
see sections 10.11.7.1 and 10.11.7.2
Port 1 receive function
see sections 10.11.7.1 and 10.11.7.3
Port 2 transmit function
see sections 10.11.7.1 and10.11.7.2
Port 2 receive function
see sections 10.11.7.1 and 10.11.7.3
Port 3 transmit function
see sections 10.11.7.1 and 10.11.7.2
Port 3 receive function
see sections 10.11.7.1 and 10.11.7.3
Port 4 transmit function
see sections 10.11.7.1 and 10.11.7.2
Port 4 receive function
see sections 10.11.7.1 and 10.11.7.3
Reserved (set to zero)
Serial Model
Reserved (set to zero)
Secondary serial port rate
Reserved (set to zero)
Reserved (set to zero)
