Index Definition

Index # Range
Profile_idx 1-16384
AOI_idx 1-8
NDR_idx 1-4

Examples of Output Frame Structure

1) Configuration with single AOI, single DC, disabled NDR mode and output of 6 profiles resulting to
a frame height of 6 rows:
ProfilesPerFrame = 6
NumAOIs
EnableDC0
EnableDC1
EnableDC2
NDRMode
Row # Description
1 Data of DC2 readout from AOI1
2 Data of DC2 readout from AOI1
3 Data of DC2 readout from AOI1
4 Data of DC2 readout from AOI1
5 Data of DC2 readout from AOI1
6 Data of DC2 readout from AOI1
C2 Series User Manual Rev. 1.9
Description
Index of Profile
Index of sensor AOI
Index of NDR frame
= 1
= false
= false
= true
= "Off"
Profile #
1
2
3
4
5
6
 31
