MAIN SUPPORTED SIGNALS

The display can store up to four types of signals for RGB adjustment values. The display uses the first-in, first-out method; therefore, the
first input signal is cleared when the fifth one is input. Input the signal you want to store and adjust to a desired screen according to
"ADJUSTING SCREEN POSITION AND SIZE". When the adjustment has been made, it is automatically stored. Thus, when the display
receives the same signal later, pictures will be displayed in accordance with the adjustment value most recently stored.
RGB1 INPUT
Display (dots x lines)
640 x 480
640 x 480
640 x 480
720 x 400
800 x 600
800 x 600
800 x 600
1024 x 768
1024 x 768
1024 x 768
1280 x 1024
1280 x 1024
848 x 480
852 x 480
1360 x 768
720 x 485
• With some input signals, "Out of range" may appear or the image may appear in black and white when the horizontal and vertical
frequencies are outside their permissible ranges, or even when the frequencies are within their permissible ranges. In this case, match the
input signal to a different frequency in the above table.
In the Component Video, HDMI and Video/S-video, the display has been factory-set as follows for different input signals:
Main corresponding signals (Comp.video, HDMI mode)
Horizontal
Vertical
frequency
frequency
(kHz)
(Hz)
15.73
59.94
31.47
59.94
45.00
60.00
33.75
60.00
67.50
60.00
RF INPUT
ANTENNA : NTSC and ATSC
CABLE
: NTSC, 64QAM and 256QAM
Note
• Depending on the input signal, the display may show pictures of reduced size due to size reduction and interpolation.
• You can check input signals through "Information" on the FEATURES Menu screen. (See P. E-39)
• All terms (i.e., company and product names) used in this document are trademarks or registered trademarks.
E-58
Horizontal frequency (kHz)
31.47
37.50
43.27
31.47
37.88
46.88
53.67
48.36
60.02
68.68
63.98
79.98
31.02
31.72
47.71
15.73
Comp.
Signal
Video
480i (SD signal)
480p (SD signal)
720p (HD signal)
1080i (HD signal)
1080p (HD signal)
-
Vertical frequency (Hz)
59.94
75.00
85.01
70.09
60.32
75.00
85.06
60.00
75.03
84.99
60.02
75.03
60.00
59.97
60.01
59.94
VIDEO1,2 INPUT (Video , S-Video mode)
Horizontal
HDMI
frequency (kHz)
15.73
Signal
VGA
VGA 75 Hz
VGA 85 Hz
400 lines
SVGA 60 Hz
SVGA 75 Hz
SVGA 85 Hz
XGA 60 Hz
XGA 75 Hz
XGA 85 Hz
SXGA 60 Hz
SXGA 75 Hz
60 fields
Vertical
Signal
frequency (Hz)
59.94
NTSC
