Summary of Contents for Fujitsu P27-9TQ
- Page 1 Display Operating Manual FUJITSU Display P27-9 TE QHD / P27-9 TS QHD...
- Page 2 Internet at: "http://www.fujitsu.com/fts/" You can find driver updates at: "http://support.ts.fujitsu.com/download" Should you have any technical questions, please contact: • our Hotline/Service Desk ("http://support.ts.fujitsu.com/contact/servicedesk") • Your sales partner • Your sales office We hope you enjoy working with your new Fujitsu system!
- Page 4 Published by / Contact address in the EU Fujitsu Technology Solutions GmbH Mies-van-der-Rohe-Straße 8 80807 Munich, Germany "http://www.fujitsu.com/fts/" Copyright © Fujitsu Client Computing Limited 2021. All rights reserved. Publication Date 04/2021 Order No.: A26361-K1693-Z320-1-19, edition 2...
-
Page 5: Table Of Contents
FUJITSU Display P27-9 TE QHD / P27-9 TS QHD Operating Manual Your LCD screen... Important notes Getting started Operation Driver installation Notes on the program "DisplayView" Notes on power management Notes on USB Power Delivery (USB-PD) Notes about the KVM function... - Page 6 Remarks Notes on the product description meet the design requirements of Fujitsu and are provided for the purposes of comparison. The actual results may differ due to several factors. Subject to technical changes without prior notification. Fujitsu accepts no responsibility for technical or editorial mistakes or omissions.
- Page 7 Notes on the program "DisplayView" ........... 43 Fujitsu...
- Page 8 Appendices ................62 Fujitsu...
-
Page 9: Your Lcd Screen
You don’t need to be an "expert" to perform the operations described here. Nonetheless, it is important to always observe the safety notes given in the operating instructions for the computer and in this manual. In the event of any problems, please contact your sales office or our Service Desk. Fujitsu... -
Page 10: Further Information
"Safety information" • cross-references to an external source, e.g. a web address: For more information, go to "http://www.fujitsu.com/fts/" • Names of CDs, DVDs and titles or designations of other materials, e.g.: "CD/DVD Drivers & Utilities" or "Safety" Manual indicates a button on the monitor, e.g:... -
Page 11: Important Notes
Use a screen saver with moving images and activate the power management for • your monitor to prevent still images from "burning in". • If you operate the device with the swivel arm or a similar accessory, it must not be turned by 180°. Fujitsu... -
Page 12: Power Cable
If the device is brought from a cold environment into the room where it will be used, condensation may occur. Before operating the device, wait until it is absolutely dry and has reached approximately the same temperature as the installation site. Fujitsu... -
Page 13: Cleaning The Device
CE marking The shipped version of this device complies with the requirements of EU directives 2014/30/EU "Electromagnetic Compatibility", 2014/35/EU "Low voltage directive", 2009/125/EU "Ecodesign directive" and 2011/65/EU "RoHS directive". Fujitsu... -
Page 14: Disposal And Recycling
"http://www.recupel.be" can be found at: environment-care/recycling/" "http://www.swico.ch" Asia Taiwan: Fujitsu America, Inc. Environmental Protection 1250E. Arques Avenue Administration Sunnyvale, CA 94085 U.S.A. Executive Yuan R.O.C. Phone No.: (408) 746-6000 "http://recycle.epa.gov.tw" You can also find information about this on the Internet at "https://www.fujitsu.com/emeia/about/local/csr/recycling/". -
Page 15: Getting Started
► Should you discover that the delivery does not correspond to the delivery note, notify your local sales outlet immediately. Do not discard the original packing material of the devices. You may need the packaging in the future if you need to transport your device. Fujitsu... -
Page 16: Setting Up The Device
To ensure sufficient ventilation, the air inlet and outlet openings of the device must be kept clear. Setting up an ergonomic video workstation ► Do not position the video workstation opposite a window (1). ► Position the monitor outside the reach of a light source (1). Fujitsu... - Page 17 Depending on the situation, it may be advisable to use a swivel arm or similar accessory (VESA FPMPMI), which are available from specialist dealers. For this purpose the monitor base must be removed beforehand as described in Chapter "Removing monitor base", Page Fujitsu...
-
Page 18: Mounting The Monitor Base
► Place the monitor in the operating position. Adjusting height The height of the monitor can be adjusted by approximately 150 mm. ► Hold the monitor with both hands on the right and left edge of the casing and move it up or down (1). Fujitsu... -
Page 19: Adjusting The Inclination
In the OSD menu you have the option of switching the OSD manually from landscape mode to portrait mode (see "Functions of the control panel and the OSD menu", Page 22). Fujitsu... -
Page 20: Removing Monitor Base
For instructions on how to mount the swivel arm or a similar accessory, please see the documentation for the swivel arm or similar accessory. The assured ergonomics and safety of the monitor may be limited if the foot provided for the monitor is not used. Fujitsu... -
Page 21: Connecting The Device
10 = Security slot for Security Lock 5 = Audio OUT socket 11 = USB-A port (USB 3.1 Gen1, Downstream) 6 = USB-C port (USB 3.1 Gen1, Upstream) 12 = USB-C port (USB 3.1 Gen1, Downstream) ► Select the appropriate data cable for your computer. Fujitsu... -
Page 22: Connecting Cables To The Computer
"Upstream" is connected to a computer. As soon as a computer gets connected via the USB-C monitor port, the active input signal is switched automatically to USB-C. When the USB-C connection is interrupted, the system automatically switches back to the last active input signal. Fujitsu... -
Page 23: Operation
The monitor is in All-In-One mode and the computer is powered down. ► Switch the device on again with the ON/OFF switch (1). You will find more information about the behaviour of the On/Off switch in All-in-One mode in chapter: "Notes on All-in-One operation", Page 48 Fujitsu... -
Page 24: Notes On The Ambient Light Sensor And Presence Sensor
find more information on this in chapter "Advanced setting functions", Page • Depending on the colour and nature of your clothes, the distance detected may deviate from the setting. • When the presence sensor is activated, the power consumption during operation is increased minimally. Fujitsu... -
Page 25: Changing The Monitor Settings
Going to the next setting Running a function Going to the previous setting Decreasing the set value Increasing the set value Accepting the applied settings and returning to the previous menu Return to the parent menu Exiting OSD menu Fujitsu... -
Page 26: Functions Of The Control Panel And The Osd Menu
When an OSD menu button is activated for the first time, the language selection window will appear: ► Press the button or the button to choose the desired language. ► Press the button to confirm. After selecting the OSD language for the first time, you can change it at any time in the OSD. Fujitsu... -
Page 27: Setting Screen Display
This setting only appears with an analogue video signal (e.g. VGA). H-position Adjust the horizontal position With this function you move the picture to the left or to the right. This setting only appears with an analogue video signal (e.g. VGA). Fujitsu... - Page 28 Full screen = maximum picture size with distortion (no black bands) Keep aspect = Maximum picture size without distortion (black bands could appear in one direction) 1:1 = Centered image without scaling (black bands could appear in both directions) The 1:1 option is not available on all models. Fujitsu...
-
Page 29: Configuring The Osd Menu
OSD submenu. ► Press the button to mark a function in the submenu. ► Press the button to make the desired setting. ► Press the button to save the settings and return to the main menu. Fujitsu... - Page 30 Auto = orientation of the OSD menu will automatically be matched to the orientation of the monitor. The Auto setting only appears on models with a rotation sensor. The On setting only appears on models without a rotation sensor. Fujitsu...
-
Page 31: Advanced Setting Functions
This setting can be used to set the distance within which you want the sensor to react. If the vertical line is outside the setting bar, this will be judged as "absent" by the presence sensor. This setting can only be applied if the Presence Sensor function is active. Fujitsu... -
Page 32: Displaying Information
With a VGA data cable, the message Auto Processing is displayed. Displaying information ► Press the button to call up the main menu. ► Press the button to call up the Information window. Details such as the model designation, serial number, resolution, H/V frequency and ECO mode are displayed. Fujitsu... -
Page 33: Activate/Deactivate Eco Operating Mode
If the brightness is further reduced by the user, this new setting is used during the next call of the ECO operating mode. After the ECO operating mode is switched off, the brightness previously set by the user is restored. Fujitsu... -
Page 34: Selecting The Input Signal
When the "Daisy-Chain" function is activated. • When the All-in-One mode is enabled (see "Notes on All-in-One operation", Page 48). Press the button To call up the INPUT settings window if the monitor is not displaying an image and is in power-saving mode. Fujitsu... -
Page 35: Selecting The Application Mode
Mode for the display of photos Increased picture definition and colour saturation. Video Mode for the display of videos Enhanced reaction time (overdrive), dynamic contrast (ACR). Custom Mode for special application purposes Free choice of colour temperature, advanced configuration capabilities. Fujitsu... - Page 36 Operation The brightness set in Mode is stored under Office, Photo, Video and Custom. Fujitsu...
-
Page 37: Setting Colour Temperature And Colours
► Press the button to select the desired colour channel. ► Press the button to make the desired setting. ► Press the button to save the settings and return to the previous menu. Fujitsu... -
Page 38: Adjusting The Volume
► Press the ► Press the button to save the settings and close the menu. Function Description Volume Set the volume for playback with the integrated loudspeakers Mute Switch the loudspeakers off or on Fujitsu... -
Page 39: Adjusting The Brightness And Contrast
Black level Setting the black level of the display With this function you modify the contrast of dark colour tones. Please note that, if you change this setting, correct colour representation can then no longer be assured. Fujitsu... -
Page 40: Locking The Osd Menu
ON/OFF button at the same time and keep them pressed for approximately 10 seconds. The message OSD locked / unlocked is displayed. Please proceed in the same manner to release the locked OSD menu again. Fujitsu... -
Page 41: Lock The On/Off Button
► Press the buttons at the same time and keep them pressed for a few seconds. The message Power button locked / unlocked is displayed. To remove the locking of the ON/OFF button again, proceed in the same way. Fujitsu... -
Page 42: Using The Daisy Chain Function
(e.g. display refresh rate, colour depth). DP1.2 ► Connect up the graphics card to the "DP IN" port or to the USB-C port (underside) on the first monitor. ► In each case, connect the next monitor to the "DP OUT" port. Fujitsu... - Page 43 (up to 5 Gbit/s) to USB 2.0 (up to 480 Mbit/s). ► Press the button To change the input signal manually. If switched to an input signal that does not support a daisy chain, the daisy chain function is disabled automatically. Fujitsu...
-
Page 44: Driver Installation
The monitor and network drivers are installed automatically whenever the Microsoft Windows operating system is updated. ► For manual installation, download the monitor and network drivers from "http://www.fujitsu.com/fts/download". Select the relevant model of monitor and operating system for this on the website. ► Unpack the zip file. -
Page 45: Monitor Drivers
► Click on Update Driver in tab Driver. ► Click on Browse my computer for driver software. ► Click on Browse, navigate to the unpacked zip file and confirm with OK. ► Click on Next and wait until the driver is installed. Fujitsu... -
Page 46: Network Drivers
► Open the directory with the unpacked contents of the network driver. ► Run the setup.exe file and follow the instructions. ► After successful installation, the device is displayed in the Device Manager under the Network Adapters header as a Realtek USB GbE Family Controller. Fujitsu... -
Page 47: Notes On The Program "Displayview
Auto brightness Contrast Black level Sharpness Apply settings to all connected monitors Undo DisplayView Can be downloaded here: "www.fujitsu.com/fts/displayview" Function overview: • OSD management for screens equipped with DDC/CI • OSD direct access for quick changes • Settings for power saving mode and security settings for the presence sensor (only for models with presence sensor) •... -
Page 48: Presence Sensor
The desktop area of the Microsoft Windows operating system can be divided into several areas into which program windows can be fitted automatically by adjusting their size. Brightness/Contrast Connected displays Mode Rotation Desktop Partitioning Desktop Partitioning Display1 Display2 Presence Sensor Desktop Partitioning Profiles Information Press left Ctrl key for Desktop Partitioning Fujitsu... -
Page 49: Notes On Power Management
ECO operation is the pre-set factory default. Once an input is made at the computer the screen contents are restored. For detailed information on how energy-saving mode operates, please refer to the operating manual or technical manual of the computer. Fujitsu... -
Page 50: Notes On Usb Power Delivery (Usb-Pd)
USB-PD again. This monitor was tested using systems developed by FUJITSU, requiring power delivery of max. 65 W via USB-PD. For other systems that only accept their own brand of USB-PD charging device due to specific power delivery directives, the... -
Page 51: Notes About The Kvm Function
If data carriers are connected to the monitor, it is advisable before changing the input signal to disable the Remove hardware safely function to prevent the loss of data. The Swap Inputs function is only enabled if a computer is connected to both of the USB ports designated as "Upstream". Fujitsu... -
Page 52: Notes On All-In-One Operation
Notes on All-in-One operation The functions described here can only be assured in combination with selected FUJITSU Notebooks, Tablets and PCs that have a native USB-C connection with integrated display port support (e.g. ESPRIMO G, LIFEBOOK, STYLISTIC). The following three functions govern All-in-One operation. -
Page 53: Lifebook / Stylistic
Charge on running: [Fast charge] USB Type-C Power Delivery Power Delivery on System-Off: [Enabled] [...] ► In the BIOS settings of your system, open the Advanced - Miscellaneous Configurations header and set Power Delivery on System-Off there to Enabled. Fujitsu... -
Page 54: Monitor
Notes on All-in-One operation Monitor ► In the OSD settings of your monitor, open the Advanced header and set the Power Button to Computer. By activating All-In-One mode, power consumption of the monitor increases in power-saving (‘Sleep’) mode. Fujitsu... -
Page 55: Operating System
On/Off switch on the monitor. Flashing at Your system is only compatible with the All-In-One mode to a limited extent. 3-second intervals It is not possible from every status to switch on the computer using the On/Off switch. Fujitsu... -
Page 56: Notes On Low Blue Light Mode
When working continuously at a display screen, it is recommended that you take a five minute break every hour. During these breaks, do eye exercises to relax your eyes. To prevent eye strain and dryness, focus regularly on objects in the distance. Fujitsu... -
Page 57: Notes On Ergonomic Colour Adjustment
+ Colour combination very suitable - Colour combination not suitable because colour hues are too close together, thin characters are not identifiable or rigorous focusing is demanded of the human eye. Fujitsu... -
Page 58: Explanatory Information About Standard Iso 9241-307
According to ISO 9241-3 (Class I), a maximum of 2 lit and 2 unlit pixels plus 9 lit or 18 unlit subpixels, or a corresponding combination, may be faulty (1 lit subpixel counts as two unlit subpixels). Because Fujitsu supplies displays that are free of pixel faults, only subpixel faults enter into the evaluation. Fujitsu... -
Page 59: Troubleshooting
Picture is wrongly adjusted ► Run the function Factory Recall (see Chapter "Advanced setting functions", Page 27). The Auto Processing message appears. Picture disturbances (vertical lines) ► Run the function Auto adjust (see Chapter "Setting screen display", Page 23). Fujitsu... - Page 60 ► Ensure that the input signal does not get changed while the computer is in power-saving mode. ► Only connect one computer to the USB port designated as "Upstream". Further information can be found in the chapter "Notes about the KVM function", Page 47 Fujitsu...
-
Page 61: Technical Specification
Condensation is not permitted, neither in the rated range of operation nor in the limit range of operation. Product name P27-9 TE QHD / P27-9 TS QHD Name of model P27-9TQ Dimensions and weight Visible diagonals 68.5 cm Dot pitch 0.233 mm... -
Page 62: Preset Operating Modes
60/75 Hz (SXGA) 1440 x 900 60 Hz (WXGA+) 1600 x 900 60 Hz (HD+) 1680 x 1050 60 Hz (WSXGA+) 1920 x 1080 60 Hz (FHD) 1920 x 1200 60 Hz (WUXGA) 2560 x 1440 60 Hz (QHD) Fujitsu... -
Page 63: Video/Tv Operating Modes Via Digital Video Inputs
HDMI port Meaning TMDS Data2+ TMDS Data2 Shield TMDS Data2– TMDS Data1+ TMDS Data1 Shield TMDS Data1– TMDS Data0+ TMDS Data0 Shield TMDS Data0– TMDS Clock+ TMDS Clock Shield TMDS Clock– N.C. DDC/CEC Ground +5 V Power Hot plug detect Fujitsu... -
Page 64: Displayport Socket
Lane 1 (negative) Earth Lane 1 (positive) Lane 0 (negative) Earth Lane 0 (positive) Connected to earth Connected to earth Auxiliary channel (positive) Earth Auxiliary channel (negative) Hot Plug Detect Return for Power Power for connector (3.3 V 500 mA) Fujitsu... -
Page 65: Usb-C Port
SuperSpeed differential pair #2, RX, negative Bus power Sideband use (SBU) Non-SuperSpeed differential pair, position 2, negative Non-SuperSpeed differential pair, position 2, positive Configuration channel Bus power SuperSpeed differential pair #3, TX, negative SuperSpeed differential pair #3, TX, positive Ground return Fujitsu... -
Page 66: Appendices
Appendices Appendices TCO: "https://support.ts.fujitsu.com/IndexDownload.asp?SoftwareGuid=0b1846d6-c0bc-4535-8ad5- 1adb49610945" ENERGY STAR®: "https://support.ts.fujitsu.com/IndexDownload.asp?SoftwareGuid=d64ffa5e-9f01-475a-9269- 975391774341" BSMI RoHS: "https://support.ts.fujitsu.com/IndexDownload.asp?SoftwareGuid=2318189a-c6bc-4691-a45d- 2c37884197b6" China RoHS: "https://support.ts.fujitsu.com/IndexDownload.asp?SoftwareGuid=e8358fb7-83a3-45ca-b707- c36a868bf0ca" Fujitsu...
