OTHER SETTINGS (FEATURES MENU) (Continued)

SETTING OTHERS

Auto Off-NO SIG.

Adjusting the settings so that the standby state automatically
starts up if the display remains in no signal state for an
extended amount of time.
Selecting the background setting to indicate when the display
is in the no signal state.
"Auto Off-NO SIG." selection screen
Time
(1) Press
or
to select the "Time".
(2) Press
or
to select the amount of time before the
standby state starts.
Off
1 min.
15 min.
Press
to store.
* The numerical value is the approximate amount of time
before the standby state starts.
Background
(3) Press
or
to select the "Background".
(4) Press
or
to select the display background color.
Black
White
Press
to store.
* The background color changes to assigned color state
after approximately 20 seconds in the no signal state.

Audio Input

"Audio Input" settings screen
Selecting the available terminals to receive audio from the
input equipment .
(1) Press
or
to select video input terminal.
(2) Select a related audio input terminal.
Each time you press
or , one of the available choices
appears in the following sequence:
No Audio
Audio1
[No Audio]: No audio in the corresponding mode. (No
audio is output even when this video input
mode is selected.)
E-38
45 min.
60 min.
Audio2
• • • • •
[Audio 1-3]: Selects Audio 1 through 3 for receiving
audio in the corresponding mode.
[Audio 4-5]: HDMI
* There is also "Audio Input" that cannot be selected.
(3) Press
to store.
* For the audio input terminals, see "CONNECTING TO
EXTERNAL EQUIPMENT" (P. E-17) and EXAMPLE OF
CONNECTING EXTERNAL EQUIPMENT" (P. E-18).
* AUDIO menu will not be displayed when "No Audio" is
selected.

Digital Audio Format

You can select the audio format for the signal output from
AUDIO OUTPUT DIGITAL terminal.
Switches as below by pressing
PCM
Dolby Digital
Press
to store.
* When a program featuring Dolby Digital audio is selected,
the sound comes from the AUDIO OUTPUT DIGITAL
terminal.
* To receive programs available in Dolby Digital sound, set the
"D Audio Format" of the on-screen menu to Dolby Digital.
• Programs that are not available in Dolby Digital sound will
be output in PCM, even if the AUDIO OUTPUT DIGITAL is
set to "Dolby Digital".

Screen Orbiter

You can use this option to move the screen position to
minimize phosphor-induced "burn-in".
Mode/Time
(1) Press
or
to select "Mode/Time".
(2) Select a desired pattern.
Each time you press
or , one of the available choices
appears in the following sequence:
Off
Time
Mode
[Off]: Disables Screen Orbiter.
[Time]: Moves the pattern approximately every one hour.
[Mode]: Moves the pattern when the power is turned ON
or when you switch between modes.
Moving Area
(3) Press
or
to select "Moving Area".
(4) Press
or
to select the range for moving the pattern.
Each time you press
or , one of the available choices
appears in the following sequence:
Min.
Std.
Max.
[Min.]: Pattern moves in small range. (About 5 pixels)
[Std.]: Pattern moves in moderate range. (About 10 pixels)
[Max.]: Pattern moves in wide range. (About 15 pixels)
(5) Press
to store.
* When the Screen Orbiter function is operated, some
screen contents. at the top, bottom, right or left of the
screen may move offscreen.
or .
for RGB
