Front Panel Controls and Indicators
Status Indicators
Ready
Cooling
Heating
2-2
Each heating station has three lights that indicate
the current status of the station. The lights flash
when gas is flowing through the heating station.
The green Ready light comes on when the set-
point temperature is below 30
temperature is below 60
and is not hot).
The yellow Cooling light comes on when the set-
point temperature of the station is less than 30
and when the actual temperature is greater than
o
60 C.
The red Heating light comes on when the setpoint
temperature is greater than 30
ing applied to the station.
SmartPrep
o
C and the actual
o
C (the station is idle
o
o
C and heat is be-
