  • Page 1 Owner’s Guide Freedom XC 2000 - 230V Freedom XC 2000 - 230V 817-2080-12 Inverter/Charger...
  • Page 2 Copyright © 2018-2020 Xantrex LLC. All Rights Reserved. All trademarks are owned by Xantrex LLC and its affiliates. Exclusion for Documentation UNLESS SPECIFICALLY AGREED TO IN WRITING, SELLER (A) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION;...
  • Page 3 Information About Your System As soon as you open your product, record the following information and be sure to keep your proof of purchase. Serial Number ____________________________ Product Number ____________________________ Purchased From ____________________________ Purchase Date ____________________________ To view, download, or print the latest revision, visit the website shown under Contact Information. 975-0821-01-01...
  • Page 4 Purpose Abbreviations and Acronyms The purpose of this Owner’s Guide is to provide explanations and Amperes procedures for installing, operating, configuring, maintaining, and Amp-hours (a unit of battery capacity) troubleshooting a Freedom XC 2000 - 230V Inverter/Charger for Recreational, Commercial and Fleet Vehicle, or Marine Alternating Current [V] installations.
  • Page 5 Degrees symbol commonly used here in degrees of ° temperature scale °C Unit of degrees in Celsius scale °F Unit of degrees in Fahrenheit scale Percent, percentage Related Information You can find more information about Xantrex products and services at http://www.xantrex.com/. 975-0821-01-01...
  • Page 6 This page is intentionally left blank. [2]...

  • Page 7: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS ’ READ AND SAVE THIS WNER UIDE FOR FUTURE DANGER REFERENCE DANGER indicates a hazardous situation which, if not avoided, will result in This guide contains important safety instructions for the Freedom death or serious injury. XC that must be followed during installation, operation, maintenance, and troubleshooting.

  • Page 8: Product Safety Information

    Product Safety Information load. Turning the inverter/charger to Standby mode using the Product Safety Information Power button on the front panel will not reduce an electrical shock hazard. 1. Before using the inverter/charger, read all instructions and cautionary markings on the unit, the batteries, and all 8.
  • Page 9 Product Safety Information DANGER DANGER ELECTRICAL SHOCK AND FIRE HAZARD HAZARD OF ELECTRIC SHOCK, EXPLOSION, BURN, OR ARC FLASH Installation must be done by qualified personnel to ensure Apply appropriate personal protective equipment (PPE) compliance with all applicable installation and electrical codes and and follow safe electrical work practices.
  • Page 10 Product Safety Information WARNING CAUTION FIRE AND EXPLOSION HAZARD ELECTRICAL SHOCK AND FIRE HAZARD Unit’s components may produce arcs or sparks. Do not open. No serviceable parts inside. Provided with Do not install near batteries, in machinery space, or in an integral protection against overloads.
  • Page 11 Product Safety Information NOTES: CAUTION Follow these instructions and those published by the battery manufacturer and the manufacturer of any equipment you intend to use in the vicinity of the battery. PHYSICAL INJURY HAZARD Review cautionary markings on these products and on the This Freedom XC 2000 - 230V Inverter/Charger is not intended for engine.

  • Page 12: Precautions When Working With Batteries

    Precautions When Working With Batteries Precautions When Working With NOTES: 1. Mount and place the Freedom XC 2000 - 230V Batteries Inverter/Charger unit away from batteries in a well ventilated compartment. IMPORTANT: Battery work and maintenance must be done by 2.

  • Page 13: Precautions When Placing The Unit

    Precautions When Placing the Unit Precautions When Placing the NOTICE Unit RISK OF INVERTER/CHARGER DAMAGE Never allow battery acid to drip on the inverter/charger when reading gravity, or filling battery. WARNING Never place the Freedom XC unit directly above batteries; gases from a battery will corrode and damage the FIRE HAZARD inverter/charger.

  • Page 14: Emissions And Immunity

    Electronic equipment such as the circuit boards, connectors, and fuses can be broken down and recycled by specialized recycling companies whose goal is to avoid having these components end up in the landfill. For more information on disposal, contact Xantrex. Freedom XC 2000 - 230V Owner's Guide...

  • Page 15: Table Of Contents

    CONTENTS Important Safety Instructions Basic Installation Procedures Product Safety Information viii Step 1: Designing the Installation Precautions When Working With Batteries Step 2: Choosing a Location for the Unit Precautions When Placing the Unit xiii Step 3: Mounting the Unit Regulatory xiii Step 4: Connecting the AC Input Wires...
  • Page 16 Viewing Information During Battery Mode Input Voltage Viewing Information During Grid Mode Overload Conditions Adjusting Settings in Configuration Mode High Surge Loads Settings Over-temperature Conditions Operating in Battery Mode Routine Maintenance Turning Inverter Operation ON and OFF Maintaining the Freedom XC Unit Troubleshooting Power Save Timer Power Save Mode...

  • Page 17: Introduction

    INTRODUCTION The Freedom XC 2000 - 230V Inverter/Charger is designed with integrated inverting functions and power management features suitable for marine, recreational, and commercial/fleet vehicle installations. Please read this section to familiarize yourself with the main performance and protection features of the Freedom XC. This section includes: Materials List Key Features...

  • Page 18: Materials List

    Freedom Figure 1 What’s In The Box XC automatically becomes an independent NOTE: If any of the items are missing, contact Xantrex or any power source that supplies utility grade AC authorized Xantrex dealer for replacement. See Contact power to your loads.
  • Page 19 Materials List Comprehensive The Freedom XC’s built-in protection features Configurable AC The Freedom XC allows two speed settings Protection safeguard your batteries (from unnecessary Transfer Speed for the AC transfer from Grid Mode to Battery drain) such as the low battery voltage alarm Mode and vice versa which avoids nuisance and shutdown and protect equipment such as resetting of appliances.
  • Page 20 Materials List Built-in Charge For the inverter/charger to perform at the Ignition Control The Freedom XC provides two user- Formulas highest level, the batteries must be charged selectable options for ignition control: correctly. The Freedom XC has optimized Ignition Auto-on: The Freedom XC can automatically turn the algorithms for flooded, gel, AGM, custom, inverter/charger on and off in tandem...
  • Page 21 Materials List Load The Freedom XC has a built-in 30A transfer Management relay (Freedom XC 2000 - 230V) that connects the inverter/charger output or AC input from the AC generator to the loads. Because the usual AC power sources such as small generators often have limited current availability, having the capability to manage your AC loads is extremely valuable.
  • Page 22 This page is intentionally left blank. [2]...

  • Page 23: Features

    FEATURES This section identifies the default settings and the hardware features of the Freedom XC 2000 - 230V Inverter/Charger. This section includes: AC and DC Panel Display Panel Side Panel 975-0821-01-01...

  • Page 24: Ac And Dc Panel

    AC and DC Panel AC and DC Panel WARNING ELECTRICAL SHOCK HAZARD Use a torque screwdriver to tighten the captive nut panel screw to 0.56 N-m torque of force to ensure a proper earth connection and a required tool access to the wiring compartment. Failure to follow these instructions can result in death, serious injury, or equipment damage.
  • Page 25 AC and DC Panel Item Description WARNING DC terminal opening for routing (+) positive DC cable. ELECTRICAL SHOCK HAZARD LED alert indicator for reverse DC polarity. Use a torque screwdriver to tighten the bolt on the DC earth lug to a torque of 2.6 N-m of force. AC output terminal opening for routing AC output wiring.

  • Page 26: Display Panel

    Display Panel Display Panel Table 2 Display Panel Features Item Description Display panel displays status information on the screen. It is comprised of a display screen, LEDs, and buttons. Multi-function LCD screen shows status information and error codes. INPUTBATTTEMP OUTPUTBATTLOAD ERROR BYPASS Status LEDs indicate the mode of operation.

  • Page 27: Side Panel

    Side Panel Side Panel Table 3 Side Panel Features Item Description Captive nut panel screw holds the wiring compartment cover in place. See WARNING above. Wiring compartment cover protects the wiring compartment from debris and keeps the cables secure. Using the captive nut panel screw, the cover can be opened and lifted out during wiring.
  • Page 28 This page is intentionally left blank. [2]...

  • Page 29: Installation

    INSTALLATION Please read this section for safety information and installation instructions regarding your Freedom XC. This section includes: Before You Begin the Installation Installation Codes Installation Tools and Materials Basic Installation Procedures Step 1: Designing the Installation Step 2: Choosing a Location for the Unit Step 3: Mounting the Unit Step 4: Connecting the AC Input Wires Step 5: Connecting AC Output to an Existing AC Circuit...

  • Page 30: Before You Begin The Installation

    Before You Begin the Installation Before You Begin the Installation Codes Governing installation codes vary depending on the specific Installation location and application of the installation. Before beginning your installation: It is the installer’s responsibility to ensure that all applicable Read this entire Installation section so you can plan the installation requirements are met.

  • Page 31: Installation Tools And Materials

    Before You Begin the Installation Installation Tools and Materials You will need the following to install the Freedom XC: Wire stripper Mounting (M2.5) screws or bolts Phillips torque screwdriver Torque wrench for DC terminals (13mm socket wrench) AC cable (that is, two-conductor-plus-earth cable), sized appropriately for load and application PG16 (or PG21) strain relief clamps (for the AC cable clamp holes)
  • Page 32 This page is intentionally left blank. [2]...

  • Page 33: Basic Installation Procedures

    Basic Installation Procedures Basic Installation Procedures This section provides sample installation information as a guide for your installation. For your convenience, the overall procedure is divided into these main steps: Step 1: Designing the Installation Step 2: Choosing a Location for the Unit Step 3: Mounting the Unit Step 4: Connecting the AC Input Wires Step 5: Connecting AC Output to an Existing AC Circuit 31...

  • Page 34: Step 1: Designing The Installation

    Basic Installation Procedures Figure 5 Typical Recreational Vehicle and Fleet Vehicle Step 1: Designing the Installation Installation Most Freedom XC installations share common components, and some of these are briefly described in Step 1: Designing the Installation. Figure 5 shows some components and their relationship to each other in a typical recreational vehicle or fleet vehicle installation.
  • Page 35 Basic Installation Procedures AC Shore Power AC Disconnect and Over-Current Protection Device A source of 230 VV 50Hz sine wave alternating current provides energy to pass power through to AC loads. This source is usually Most safety requirements and electrical codes require the the utility grid (power company) or an AC generator.
  • Page 36 Basic Installation Procedures AC Distribution Panels Each system requires a method of disconnecting Disconnect the AC circuits. If the over-current protection Devices Most systems incorporate distribution centers both ahead of the devices are circuit breakers, they will also serve as Freedom XC (the AC source panel) and between the Freedom XC the disconnects.
  • Page 37 Basic Installation Procedures AC breakers and fuses must be sized to adequately protect the AC Output Neutral Bonding Option (Earth wiring that is installed on the input and output AC circuits of the Relay Function) Freedom XC. All breakers and wiring must be sized and The earth relay function allows you to connect the neutral connected in accordance with the electrical codes or regulations conductor (N) of the inverter output circuit to the safety earth...
  • Page 38 Basic Installation Procedures 3. Using a Phillips torque screwdriver, attach the bonding DC Cabling screw to the AC Out Neutral-to-Earth Bond hole. This includes all the cables and connectors between the batteries, 4. Tighten the bonding screw to 0.85 N-m maximum torque. the DC disconnect and over-current protection device, and the AC Earthing Freedom XC.
  • Page 39 Basic Installation Procedures heavy load the Freedom XC can draw current surges from the battery of up to 250A. If the DC wiring is too small the voltage drop from this surge will result in a voltage at the Freedom XC terminals that is too low for the Freedom XC to operate correctly.

  • Page 40: Step 2: Choosing A Location For The Unit

    Basic Installation Procedures Ventilated. Allow at least 12 cm of clearance at the wiring Step 2: Choosing a Location for the access (AC and DC) end of the Freedom XC allowing air Unit intake flow through the fans. Provide similar clearance at the opposite end where the air vent is located.

  • Page 41: Step 3: Mounting The Unit

    Basic Installation Procedures Figure 7 Approved Mounting Orientations Step 3: Mounting the Unit To mount the Freedom XC: 1. Remove the Freedom XC from its shipping container, verify that all components are present, and record relevant product information on “Information About Your System” in the Owner’s Guide.
  • Page 42 Basic Installation Procedures Connecting the Equipment Earth Earthing Locations You must connect the equipment earth lug to an earthing point— usually the vehicle’s chassis or DC negative bus earth—using WARNING recommended copper wire (if insulated then green insulation with or without one or more yellow stripes) or larger. ELECTRIC SHOCK HAZARD Make sure to tighten the bolt on the DC earth lug to a torque of Never operate the Freedom XC without properly connecting the...

  • Page 43: Step 4: Connecting The Ac Input Wires

    Basic Installation Procedures AC Wiring Connectors Step 4: Connecting the AC Input Wires Where applicable, connect AC wires with crimp-on splice connectors. The amount of insulation you strip off individual wires WARNING will be specified by the connector manufacturer and is different for different types of connectors.
  • Page 44 Basic Installation Procedures AC wiring must be sized appropriately using conductors with NOTICE insulation rated at least 75 °C to carry full load current on the input and output AC circuits in accordance with the electrical codes or REVERSE POLARITY DAMAGE regulations applicable to your installation.
  • Page 45 Basic Installation Procedures Figure 10 Routing the AC input wires WARNING ELECTRIC SHOCK HAZARD Use a screwdriver to loosen the captive nut panel screw. Failure to follow these instructions can result in death, serious injury, or equipment damage. Figure 9 Loosening the captive nut panel screw step 8a step 8b step 8c...
  • Page 46 Basic Installation Procedures 8. Connect each AC wire into its corresponding terminal on the no-tool cage clamp terminal block. a. Lift the terminal lever (as shown in the previous figure). b. Insert the wire fully into the open slot. c. Lower the terminal lever to secure the wire in the slot. 9.

  • Page 47: Step 5: Connecting Ac Output To An Existing Ac Circuit

    Basic Installation Procedures Step 5: Connecting AC Output to an NOTICE Existing AC Circuit EQUIPMENT DAMAGE Do not connect any AC source (such as a generator or WARNING utility power) to the AC output wiring of the Freedom ELECTRIC SHOCK AND FIRE HAZARDS The Freedom XC will not operate if its output is connected to AC voltage from a source, and potentially hazardous or Make sure wiring is disconnected from all electrical sources...
  • Page 48 Basic Installation Procedures 2. Install the required circuit breaker in the inverter/charger AC Output Connections distribution panel receiving AC power from the Figure 11 Routing and connecting the AC output wires inverter/charger. 3. Remove the wiring compartment cover, if not already done from AC Output Connections on page 32.
  • Page 49 Basic Installation Procedures 9. Tighten the strain relief clamp to secure the wires. 10. Replace the wiring compartment cover (using a #2 (3.5mm) Phillips torque screwdriver - see WARNING), if you are finished with connecting all the AC wires in the unit. WARNING ELECTRICAL SHOCK HAZARD Use a torque screwdriver to tighten the captive nut panel screw to...

  • Page 50: Step 6: Connecting The Dc Cables

    Basic Installation Procedures Follow the procedure given below to connect the battery leads to Step 6: Connecting the DC Cables the terminals on the DC end. The cables should be as short as possible and large enough to handle the required current, in NOTICE accordance with the electrical codes or regulations applicable to your installation.
  • Page 51 Basic Installation Procedures 6. Strip 13 to 19 mm of insulation from each cable end that will To make the DC connections: be connected to the inverter/charger cable. The amount 1. Make sure the inverter/charger is off and no AC or DC is stripped off will depend on the terminals chosen.
  • Page 52 Basic Installation Procedures Figure 13 DC Cable Connections WARNING ELECTRICAL SHOCK HAZARD Tighten the nuts on the DC terminals properly. Loose connections cause excessive voltage drop and may cause overheated wires and melted insulation. Do not over-tighten the nut on the DC input terminals because damage to the DC input terminals may result.
  • Page 53 Basic Installation Procedures 15. Replace the wiring compartment cover by tightening the WARNING captive nut panel screw. See the following electrical shock hazard warning. FIRE HAZARD WARNING Do not complete the next step if flammable fumes are present. Explosion or fire may result if the disconnect/battery selector switch ELECTRICAL SHOCK HAZARD is not in the off position.
  • Page 54 Basic Installation Procedures DC Earthing For DC voltage systems under 50 VZ in an RV installation, an 8.36mm Regulatory copper bonding conductor would be acceptable for the inverter/charger enclosure To connect the DC earth: references earth bonding only. The "house" battery system must, however, be earth bonded. 1.

  • Page 55: Step 7: Connecting To Port(S) On The Freedom Xc

    Basic Installation Procedures Figure 14 Ignition signal (ACC) input terminal Step 7: Connecting to Port(s) on the Freedom XC Connecting to ACC Signal With the ACC, the Freedom XC can be wired to inhibit inverter operation in the absence of a vehicle’s (or vessel's) +12VZ ignition control signal.
  • Page 56 Basic Installation Procedures Description of Ignition Control Features Connecting to the Remote Port For information about the features and instructions on changing The Freedom XC can accommodate the Freedom X Remote the ignition control features, see Operation on page 45. Panel with cable (PN: 808-0817-01) (sold separately;...

  • Page 57: Step 8: Testing Your Installation

    Basic Installation Procedures Testing in Battery Mode Step 8: Testing Your Installation To test the Freedom XC: 1. For hard wired installations, ensure shore power is not WARNING present. 2. Press the Power button to turn the inverter/charger on. ELECTRIC SHOCK HAZARD The green LED indicating Battery mode (Inverter mode) Pressing the Power button to turn the Freedom XC inverter to turns on and the LCD screen displays the BATT.
  • Page 58 Basic Installation Procedures Testing in Grid Mode To test the Freedom XC: With the test load from the previous test still connected and operating, connect the shore power source. The Freedom XC transfers the test load to shore power. The green LED indicating grid mode turns on and the LCD screen displays the AC MODE icon.

  • Page 59: Marine Installation

    Marine Installation Marine Installation Figure 15 Typical Marine Installation Figure 15 illustrates a typical marine installation with the following components: Equipment earth – Engine negative bus / DC earth bus Freedom XC DC fuse/disconnect/DC circuit breaker 12V deep cycle battery bank (house) and protected by a DC fuse in the positive cable Battery isolator DC alternator...

  • Page 60: Drip Shield Installation

    Marine Installation Drip Shield Installation Figure 16 Drip shields To install the drip shields: The drip shields help to protect the unit from dripping or splashing 1. Gather the four screws needed liquids, which will cause a shock hazard when moisture comes in to fasten a single drip shield to a contact with electrical circuits in the unit.

  • Page 61: Operation

    OPERATION This section includes descriptions of the different modes and settings of the Freedom XC 2000 - 230V Inverter/Charger. This section includes: Freedom XC Display Panel Status LED Indicators Function Buttons LCD Screen LCD Screen Icons 975-0821-01-01...

  • Page 62: Freedom Xc Display Panel

    Freedom XC Display Panel Freedom XC Display Panel Status LED Indicators Figure 18 Display Panel Indicator Definition Solid green. Indicates grid mode in which shore power is available and passing through to the loads and charging the INPUTBATTTEMP OUTPUTBATTLOAD    battery.

  • Page 63: Function Buttons

    Freedom XC Display Panel Function Buttons LCD Screen The LCD Screen changes depending on the operating mode of the Button Definition inverter/charger. Figure 19 Parts of the LCD Screen Return to default screen or exit setting mode. Scroll to next screen or next selection. Press and hold for 3 s to scroll back one step.

  • Page 64: Lcd Screen Icons

    Freedom XC Display Panel LCD Screen Icons Icon Definition The load icon is displayed if there is Icon Definition voltage available at the AC output. AC input and output indicator. The wrench icon underneath a number is The bar represents load consumption displayed during configuration mode.

  • Page 65: Viewing Information During Battery Mode

    Viewing Information During Battery Mode Viewing Information During Info and Setting LCD Screen Battery Mode The LCD screen displays information related to battery mode operation. Screen 2 of 4 - Press the Scroll button to move from screen to screen. AC Output Press and hold for 3 s to go back one step.
  • Page 66 Viewing Information During Battery Mode Info and Setting LCD Screen Screen 4 of 4 - Firmware version Firmware version = U1 1.01 Freedom XC 2000 - 230V Owner's Guide...

  • Page 67: Viewing Information During Grid Mode

    Viewing Information During Grid Info and LCD Screen Mode Setting 1. The LCD screen displays information related to AC bypass or charger operation. 2. Press the Scroll button to move from screen to screen. 3. Press to return to the home screen. Screen 1 of NOTE: After 1 min of inactivity in the other screens, the LCD will 5 - Battery...
  • Page 68 Info and Info and LCD Screen LCD Screen Setting Setting Screen 2 of Screen 4 of Battery AC input Voltage/ voltage/AC Charging input Current frequency battery voltage = 12.5VZ, charging current = 60A input voltage = 230VV, input frequency = 50Hz Screen 3 of Screen 5 of AC input...

  • Page 69: Adjusting Settings In Configuration Mode

    Adjusting Settings in Configuration Mode Adjusting Settings in To change the default value to a different value: 1. Press and hold the button for 3 s to enter the Configuration Mode Configuration mode. 2. Press the Scroll button to scroll through the different , Scroll , and buttons can be used to cycle...

  • Page 70: Settings

    Adjusting Settings in Configuration Mode Settings Setting Default Range of Setting Name Description Number Value Values Inverter Ignition Control See Description of Ignition Control Features on page 40. The voltage setting value can be adjusted by 0.1 increments. The 10.5 10.0 to 12.8 LBCO Voltage inverter is able to recover automatically at LBCO voltage + 2.0 V...
  • Page 71 Adjusting Settings in Configuration Mode Setting Default Range of Setting Name Description Number Value Values After changing the output frequency setting, turn the unit off and Output Frequency then on again, in order for the change to take effect. Output Voltage In VV Inverter Output Power The wattage setting value can be adjusted by 100-W increments.
  • Page 72 Adjusting Settings in Configuration Mode Setting Default Range of Setting Name Description Number Value Values The inverter shuts down when there is an over temperature, overload, and short circuit condition. Selecting ATO (auto-restart) At0(auto- will allow the inverter/charger to recover automatically from a Inverter Shutdown restart) shutdown up to three times maximum.
  • Page 73 Adjusting Settings in Configuration Mode Setting Default Range of Setting Name Description Number Value Values Custom Absorption 14.6 12.0 to 18.0 The voltage setting value can be adjusted by 0.1 increments. Voltage Available only when custom battery type is selected. 13.5 12.0 to 18.0 Custom Float Voltage...

  • Page 74: Operating In Battery Mode

    Operating in Battery Mode Operating in Battery Mode Turning Inverter Operation ON and OFF There are two ways to operate the Freedom XC’s inverter The Freedom XC is in Battery Mode (also called Inverter Mode) function. when all the following conditions exist: 1.

  • Page 75: Power Save Timer

    Operating in Battery Mode Power Save Timer Checking Battery Status The Power Save Timer is an adjustable countdown timer from 1 to During inverter operation (in battery mode), you can check the 25 h (25 h is the default) that automatically shuts down inverter battery status by observing the battery capacity indicator on the operation to reduce battery discharge and preserve battery life.

  • Page 76: Turning The Audible Alarm On Or Off

    Operating in Battery Mode Turning the Audible Alarm ON or OFF The Freedom XC’s audible alarm can be muted. See Adjusting Settings in Configuration Mode on page 53. Any warnings such as error or fault conditions or imminent shutdown are both displayed on the LCD screen and sounded on the alarm speakers.

  • Page 77: Operating In Grid Mode

    Operating in Grid Mode Operating in Grid Mode Battery Types The Freedom XC 2000 - 230V Inverter/Charger charges flooded (or wet) lead-acid, Gel, AGM (absorbed glass mat), custom, and Battery Charger Functions lithium iron phosphate (LFP) batteries. When AC power is available, the Freedom XC can operate as a Flooded (or wet) batteries have removable battery caps for 12-VZ battery charger.
  • Page 78 Operating in Grid Mode There is a fourth stage, equalization, which is initialized manually NOTICE as it is only performed occasionally and only on flooded (or wet) batteries. BATTERY DAMAGE The charging cycle is a multistage (three-stage) process. Do not mix battery types. The Freedom XC can only select one battery type setting for all batteries connected to its bank.
  • Page 79 Operating in Grid Mode Bulk Stage The Freedom XC has been in absorption for the programmed maximum absorption time limit. The default is 6 h. Bulk charge is the first stage in the charging process and provides the batteries with a controlled, constant current. Once the battery NOTE: If there are DC loads on the batteries, the charger’s voltage rises to the absorption voltage threshold, the charger current may never decrease to a level to initiate the next stage of...
  • Page 80 Operating in Grid Mode Equalize Charging Table 11 Preset Float Voltage Settings Many battery manufacturers recommend periodic equalize Battery Type Preset Float Voltage charging to counter cell charge imbalance and capacity-robbing Flooded 13.5 electrolyte stratification. Equalizing helps to improve battery performance and lifespan by encouraging more of the battery 13.8 material to become active.

  • Page 81: Custom Battery Settings Menu

    Operating in Grid Mode Figure 21 Equalize charging Custom Battery Settings Menu NOTICE REVERSE POLARITY To avoid damaging your batteries during charging or equalization, consult your battery manufacturer and associated documentation before setting a custom battery type. Failure to follow these instructions can result in equipment damage.

  • Page 82: Operating During Transition Between Grid Mode And Battery Mode

    Operating During Transition Between Grid Mode and Battery Mode Operating During Transition Transitioning from Grid Mode to Battery Mode Between Grid Mode and Battery When the unit is operating in grid mode and shore power is lost, Mode the Freedom XC has less than 20 milliseconds (default) to switch The Freedom XC’s advanced power management is capable of to operating in battery mode (if the Power button is pressed in the transitioning power from an AC source to DC source within a...

  • Page 83: Operating Limits

    Operating Limits Operating Limits Power Output The Freedom XC can deliver up to 2000 W of continuous utility These are the operating limits of the Freedom XC: grade sine wave AC power. The wattage rating applies to resistive Power Output loads such as incandescent lights. Input Voltage Overload Conditions High Surge Loads...

  • Page 84: Input Voltage

    Operating Limits Input Voltage Operating Battery Comment The allowable Freedom XC input battery voltage ranges are Condition Voltage shown in the following table: The buzzer sounds a single 1 s Table 12 Input battery voltage range low battery alarm beep and the LCD screen shows error code Operating Battery...

  • Page 85: Overload Conditions

    Operating Limits Overload Conditions Operating Battery Comment There are two kinds of overload conditions – an overload warning Condition Voltage and an overload shutdown. The display shows error code Overload When the Freedom XC’s AC load is approximately 100 W E02 alternating with the battery Warning below the overload shutdown limit of rated watts, the voltage.

  • Page 86: Over-Temperature Conditions

    Operating Limits Over-temperature Conditions During inverter operation, when the Freedom XC’s internal temperature starts to approach its preset shutdown limit, the display will show error code E07. If the over-temperature condition persists, the display will show error code E04. The Status LED turns solid RED and the inverter/charger will shut down to prevent damage to the inverter/charger and protect the battery from being over-discharged.

  • Page 87: Routine Maintenance

    5 ROUTINE MAINTENANCE Regular maintenance is required to keep your Freedom XC operating properly. This section includes: Maintaining the Freedom XC Unit 975-0821-01-01...

  • Page 88: Maintaining The Freedom Xc Unit

    Maintaining the Freedom XC Unit Maintaining the Freedom XC Unit WARNING ELECTRICAL SHOCK HAZARD Turning the Power k button to Standby mode does not disconnect DC battery power from the Freedom XC. You must disconnect from all power sources before working on any circuits connected to the unit.

  • Page 89: Troubleshooting

    TROUBLESHOOTING This section will help you narrow down the source of any problem you encounter. Before contacting customer service, please work through the steps listed in Pre-service Checklist on page 74. This section includes: Pre-service Checklist Warning Messages Troubleshooting Reference 975-0821-01-01...

  • Page 90: Pre-Service Checklist

    Pre-service Checklist Whether any extreme ambient conditions existed at Pre-service Checklist the time (temperature, vibrations, moisture, etc.) 3. If your Freedom XC is not displaying an error code, check the following to make sure the present state of the WARNING installation allows proper operation: Is the inverter/charger located in a clean, dry, ELECTRICAL SHOCK HAZARD...

  • Page 91: Warning Messages

    Warning Messages Warning Messages Warning messages in the form of audible alarms and error codes that appear on the LCD screen to alert you to an impending system change. Warnings do not affect operation. With the exception of the error codes displayed on the screen, only the audible alarm can be turned ON or OFF.
  • Page 92 Warning Messages Table 13 Error codes displayed on the LCD screen Error Code Condition Mode Action Low battery voltage shutdown is imminent Check battery status and recharge if necessary. depending on the setting, Battery mode Check for proper DC cable sizing. see Maintaining the (inverting) Check for loose connections and tighten if necessary.
  • Page 93 Warning Messages Error Code Condition Mode Action Reduce the loads connected to the AC outlet of the unit. Check that the ventilation grille is not blocked. Over-temperature alarm Battery mode Check for ambient temperature and move the unit to a cooler and fan lock alarm (inverting) location whenever possible.

  • Page 94: Troubleshooting Reference

    Troubleshooting Reference Troubleshooting Reference WARNING ELECTRICAL SHOCK HAZARD Do not disassemble the Freedom XC. It does not contain any user- serviceable parts. Attempting to service the unit yourself could result in an electrical shock or burn. Failure to follow these instructions can result in death, serious injury, or equipment damage.
  • Page 95 Troubleshooting Reference Table 14 Troubleshooting reference Problem Possible Cause Solution Alarm does not sound when an error is Alarm is turned OFF. See Turning the Audible Alarm ON or OFF on page 60 encountered. and follow instructions to turn the alarm buzzer on again.
  • Page 96 Troubleshooting Reference Problem Possible Cause Solution No output voltage is shown in the LCD RCBO (when installed Check load and reset the RCBO or supplementary screen but the green status LED for downstream) has tripped or breaker. Battery mode is illuminated. supplementary breaker has tripped.
  • Page 97 Troubleshooting Reference Problem Possible Cause Solution No output voltage. The status LED is Ignition lock (ACC) signal is not If the ignition control feature is in use, ensure the not lighting up. present. vehicle’s ignition is On and the ignition control switch on the front of the Freedom XC unit is On (|).

  • Page 98: Inverter Applications

    Inverter Applications Inverter Applications Motor Loads Induction motors (that is, motors without brushes) require two to The Freedom XC performs differently depending on the AC loads six times their running current on start up. The most demanding connected to it. If you are having problems with any of your loads, are those that start under load, for example, compressors and read this section.

  • Page 99: Problem Loads

    Inverter Applications When the Freedom XC is in power save mode, it may fail to start Problem Loads some loads even though the rated wattage on the load is more Very Small Loads If the power consumed by a device is less than 25 W.
  • Page 100 This page is intentionally left blank. [2]...

  • Page 101: Specifications

    SPECIFICATIONS This section summarizes the hardware and electrical specifications of the Freedom XC 2000 - 230V Inverter/Charger. Physical Specifications Environmental Specifications System Specifications Regulatory Approvals NOTE: Specifications are subject to change without prior notice. 975-0821-01-01...

  • Page 102: Physical Specifications

    Physical Specifications Physical Specifications Environmental Specifications Table 15 Physical specifications Table 17 Environmental specifications Freedom XC 2000 - 230V Freedom XC 2000 - 230V Ambient Temperature: 390mm × 275mm × 102mm without flanges. L × W × H    Operating Temperature Range -20 –60 ºC, with output derated 390mm ×...

  • Page 103: System Specifications

    System Specifications System Specifications Table 19 DC input for inverting Freedom XC 2000 - 230V Table 18 System specifications 10–17.0 V Z Operating voltage range Freedom XC 2000 - 230V Maximum non-operating voltage 25.2 V Z Transfer relay rating (A 30A V 12.0 V Z Nominal voltage Transfer time (ms...
  • Page 104 System Specifications Table 21 AC input for charging Freedom XC 2000 - 230V Freedom XC 2000 - 230V May reduce charger current Charger current derating depending on ambient Operating voltage range 170–280 VV temperature. Safe non-operating voltage up to 300 VV ≥91% Efficiency at nominal output range 5.6 A V...

  • Page 105: Regulatory Approvals

    Regulatory Approvals Regulatory Approvals Table 23 Regulatory approvals Freedom XC 2000 - 230V Compliance with CE Marking: Low Voltage Directive (2014/35/EU) Safety For marine installations, use of drip shield with product number 808-1050 is required. Compliance with CE Marking: Electromagnetic Compatibility (EMC) Directive (2014/30/EU) and E Mark, Automotive EMC Regulation 10R06...
  • Page 106 (Toll Free USA/Canada) +1 800 670 0707 (Outside USA/Canada) +1 408 987 6030 Printed in: 975-0821-01-01 Rev C...
