  • Page 1 Web: www.xantrex.com Email: CustomerService@xantrex.com Phone: 1-604-422-8595 Phone: 1-800-670-0707 (toll free in North America) Fax: 1-604-420-1591 Fax: 1-800-994-7828 (toll free in North America) Xantrex Inverter 300 Owner’s Guide...

  • Page 2: Contact Information

    About Xantrex Xantrex Technology Inc. is a world-leading supplier of advanced power electronics and controls with products from 50 watt mobile units to 1 MW utility-scale systems for wind, solar, batteries, fuel cells, microturbines, and backup power applications in both grid-connected and stand-alone systems.

  • Page 4: Table Of Contents

    AC Outlets ....... . . 7 4. Connecting the 300 Inverter ....8 Choosing a Location .

  • Page 6: Introduction

    1 Introduction Thank you for purchasing the Xantrex 300 Inverter. The 300 Inverter is part of a family of advanced, high- performance power inverters from Xantrex, the leader in the field of high-frequency inverter design. Connected to the 12 volt outlet in your vehicle or boat or...

  • Page 7: Important Safety Information

    • Warning statements identify conditions that could result in personal injury or loss of life. • Caution statements identify conditions or practices that could result in damage to the 300 Inverter or other equipment. Warnings and Cautions Shock hazard. Warning! The 300 Inverter generates the same potentially lethal AC power as a household wall outlet.
  • Page 8 Warning! Risk of fire or explosion. The 300 Inverter contains components that tend to produce arcs or sparks. To prevent fire or explosion, do not install the inverter in compartments containing batteries or flammable materials or in locations that require ignition- protected equipment.
  • Page 9 These chargers have a warning label stating that dangerous voltages are present at the charger battery terminals. Do not use the 300 Inverter with the type of appliances just described. Risk of damage due to high Caution! temperatures.

  • Page 10: Xantrex 300 Inverter Features

    It allows you to plug in a 230 volt AC product with a power consumption of 150 watts or less when the inverter is operated from a vehicle lighter socket, or 300 watts or less when it is connected directly to a battery.
  • Page 11 When the inverter is connected to a DC power source and the On/Standby switch is on, AC power is available at the outlet. The green light is on all the time when Power Light the On/Standby switch is on. The red light indicates that the Fault Light inverter has shut down because of low or high battery...

  • Page 12: Ac Outlets

    AC Outlets Depending on your geographic location, your 300 Inverter will have one of the following AC outlets. Figure 2 European AC Figure 3 British AC Outlet Outlet Figure 4 Australian and New Zealand AC Outlet...

  • Page 13: Connecting The 300 Inverter

    4 Connecting the 300 Inverter This section explains how to connect the 300 Inverter. Choosing a Location For the best performance, choose a location that is: • Dry Do not expose the inverter to water drip or spray. • Cool Operate the inverter in ambient temperatures between 0°...

  • Page 14: Connecting The 300 Inverter To Dc Power

    Connecting the 300 Inverter to DC Power Risk of damage to the 300 Inverter. Caution! The 300 Inverter must only be operated with a nominal 12 volt battery. The inverter will not operate with a lower voltage battery. A higher voltage battery will damage the inverter.

  • Page 15: Using The Cigarette Plug Wire Assembly

    Place the black ring connector on the inverter’s black (negative –) DC terminal, and then screw the black nut on until it is snug. Do not over tighten. Damage to the 300 Inverter. Caution! Reversing the positive and negative battery cables will damage the inverter and will void your warranty.

  • Page 16: Using The Battery Clip Wire Assembly

    Using the Battery Clip Wire Assembly When you are going to power Loads greater than 150 watts loads that are greater than 150 watts (up to 300 watts continuous power), connect the inverter to a 12 volt battery using the battery clip wire assembly.
  • Page 17 Risk of damage to the 300 Inverter. Caution! Reversing the positive and negative battery cables will damage the inverter and void your warranty. When you connect the inverter to the battery, double check the connections. The red wire must be connected to the red (+) terminal on the inverter and the positive (+) terminal on the battery.

  • Page 18: Hardwiring The Inverter To The Battery

    AC power is available at the outlet. Hardwiring the Inverter to the Battery Loads of any size (up to 300 watts continuous power) permanent electrical connection, or when you need to power some loads that are greater than 150 watts and some that are less than 150 watts, you can hardwire the inverter to the battery.
  • Page 19 Figure 6 Hardwiring the 300 Inverter to a 12 Volt Battery 300 Inverter 3.3mm (12 AWG) red wire from the positive inverter terminal to the positive battery terminal (via the fuse and the switch) 40 amp automotive fuse 12 volt, 40 amp disconnect switch battery 3.3mm...
  • Page 20 (12 AWG) wire or heavier, extend the power cord if you need to, to a maximum total length of 2 meters (6.5 feet) including the existing 300 Inverter power cord length. Solder all connections and make sure they are properly insulated by using electrical tape or heat shrinkable tubing.
  • Page 21 Risk of damage to the 300 Inverter. Warning! Reversing the positive and negative battery cables will damage the inverter and will void your warranty. Before connecting the inverter to the battery, double check the connections: the red wire must be connected to the red terminal on the inverter and the positive (+) terminal on the battery;...

  • Page 22: Disconnecting The Battery

    Disconnecting the Battery • Before you disconnect the battery, turn off the AC load, and then turn off the in-line switch. Replacing the In-Line Fuse • If you need to replace the in-line fuse (see turn off the in-line switch to disconnect the DC power. Figure...

  • Page 23: Operating The 300 Inverter

    • Possible shutdown when the vehicle’s engine is started The 300 Inverter will operate while your vehicle’s engine is running, but the normal voltage drop light comes on, and AC...
  • Page 24 • AC Overload Shutdown If you connect an AC load rated higher than 300 watts or 1.3 amps or that draws excessive surge power, the 300 Inverter shuts down. light stays on, and the to indicate that the inverter is overloaded.

  • Page 25: Interference With Electronic Equipment

    Buzzing Sound Some inexpensive stereo systems and “boom boxes” have inadequate internal power supply filtering and buzz slightly when powered by the 300 Inverter. The best solution is to have an audio system with a good quality filter. Television Interference The 300 Inverter is shielded to minimize its interference with TV signals.

  • Page 26: Battery Operating Time

    • Do not leave the 300 Inverter on for more than a week if you do not have an AC load connected to it. The inverter draws less than 0.2 amps with the On/ Standby switch on and no load connected, but that will eventually discharge the battery.

  • Page 27: Troubleshooting

    Suggested remedy The AC load is rated at more Use an AC load with a power than 300 watts; an overload rating less than 300 watts (1.3 shutdown has occurred. amps). The AC load is rated at less The AC load exceeds the than 300 watts, but a high inverter’s surge capability.
  • Page 28 The AC load does not operate. The Symptom comes on when the inverter is turned on or when the AC load is turned on or plugged in. The alarm may sound. Possible cause Suggested remedy The battery is discharged. Recharge the battery. The battery voltage is Check the charging system.
  • Page 29 The AC load will not operate; no inverter lights are The cigarette lighter works in the lighter socket, Symptom but the inverter does not. Possible cause Suggested remedy The contact between the plug Press the plug firmly into the and the lighter socket or the 12 socket.
  • Page 30 The inverter is cool or warm to touch. Possible cause Suggested remedy The battery is old or defective. Replace the battery. The battery is not being charged Have a qualified technician properly. check the vehicle’s electrical system. 300 Inverter...

  • Page 31: Warranty Information

    8 Warranty Information Xantrex manufactures its What Does This Warranty Cover? products from parts and components that are new or equivalent to new, in accordance with industry standard practices. This warranty covers any defects in workmanship or materials. This warranty lasts for How Long Does The Coverage Last? two (2) years from the date of purchase.

  • Page 32: Returning A Product

    building replacement products. If Xantrex repairs or replaces a product, its warranty term is not extended. Xantrex owns all parts removed from repaired products. In order to qualify for the Service During Warranty warranty, dated proof of purchase must be provided and the product must not be disassembled or modified without prior authorization by Xantrex.

  • Page 33: Out-Of-Warranty Service

    Out-of-Warranty Service If the warranty period for your 300 Inverter has expired, if the inverter was damaged due to misuse or incorrect installation, if other conditions of the warranty have not been met, or if no dated proof of purchase is available, your inverter may be serviced or replaced for a flat fee.
  • Page 34 To return your 300 Inverter for out-of-warranty service, contact Xantrex customer service for a Return Material Authorization (RMA) number, and follow the other steps outlined in “To Xantrex” on page 27. Options for payment, such as credit card or money order, will be explained by the customer service representative.

  • Page 35: Specifications

    Over-temperature shutdown Overload shutdown Internal fuse 230 volts AC RMS ± 5% 50 ± 3 Hz Modified Sine Wave 300 watts 600 watts 10–15 volts DC 0.20 amps 0° C–40° C (32° F–105° F) 10.7 volts DC 10.0 volts DC 15.0 volts DC...

  • Page 36: Physical

    Physical Dimensions (L x W x H) Weight Regulatory CE Mark e Mark TUV/Type approved 200mm x 103mm x 66mm (7.9 in. x 4.1 in. x 2.6 in.) 0.79 Kg (1.74 lb.) Low Voltage Directive EMC Directive Automotive EMC Directive Certified to EN60950...
