Freedom XC 2000 (230VAC)
Inverter/Charger
Owner's Guide
Freedom XC 2000 (230VAC)
817-2080-12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Freedom XC 2000 and is the answer not in the manual?

Questions and answers

steve
March 14, 2025

Xantrex(3 years old) shows code 10. Won't reset. Wint invert or charge. Why

0

Subscribe to Our Youtube Channel

Related Manuals for Xantrex Freedom XC 2000

Summary of Contents for Xantrex Freedom XC 2000

  • Page 1 Owner’s Guide Freedom XC 2000 (230VAC) Freedom XC 2000 (230VAC) 817-2080-12 Inverter/Charger...
  • Page 2 Copyright © 2018 Xantrex LLC. All Rights Reserved. All trademarks are owned by Xantrex LLC and its affiliates. Exclusion for Documentation UNLESS SPECIFICALLY AGREED TO IN WRITING, SELLER (A) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION;...
  • Page 3 Information About Your System As soon as you open your product, record the following information and be sure to keep your proof of purchase. Serial Number ____________________________ Product Number ____________________________ Purchased From ____________________________ Purchase Date ____________________________ To view, download, or print the latest revision, visit the website shown under Contact Information. 975-0821-01-01...
  • Page 4 Analyzing and reducing the hazards involved in performing electrical work. Wattage Selecting and using Personal Protective Equipment (PPE). Abbreviations and Acronyms Related Information You can find more information about Xantrex products and Amperes services at http://www.xantrex.com/. Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS ’ READ AND SAVE THIS WNER UIDE FOR FUTURE DANGER REFERENCE DANGER indicates a hazardous situation which, if not avoided, will result in This guide contains important safety instructions for the Freedom death or serious injury. XC that must be followed during installation, operation, maintenance, and troubleshooting.

  • Page 6: Product Safety Information

    7. To reduce the risk of electrical shock, disconnect both AC and DC power from the inverter/charger before attempting any maintenance or cleaning or working on any components connected to the inverter/charger. Do not disconnect under Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 7 See IEC / EN regulations. Instructions for installing the Freedom XC 2000 60364-x-y series of standards. (230VAC) Inverter/Charger are provided here for use by qualified This equipment must only be installed and serviced by personnel only.
  • Page 8 75°C. compartment. Failure to follow these instructions can result in injury or Failure to follow these instructions can result in death, serious equipment damage. injury, or equipment damage. viii Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 9 PHYSICAL INJURY HAZARD Review cautionary markings on these products and on the This Freedom XC 2000 (230VAC) Inverter/Charger is not intended engine. for use by persons (including children) with reduced physical,...

  • Page 10: Precautions When Working With Batteries

    Precautions When Working With Batteries Precautions When Working With NOTES: 1. Mount and place the Freedom XC 2000 (230VAC) Batteries Inverter/Charger unit away from batteries in a well ventilated compartment. IMPORTANT: Battery work and maintenance must be done by 2. Always have someone within range of your voice or close...

  • Page 11: Precautions When Placing The Unit

    Precautions When Placing the Unit Precautions When Placing the NOTICE Unit RISK OF INVERTER/CHARGER DAMAGE Never allow battery acid to drip on the inverter/charger when reading gravity, or filling battery. WARNING Never place the Freedom XC unit directly above batteries; gases from a battery will corrode and damage the FIRE HAZARD inverter/charger.

  • Page 12: Emissions

    Many of the electrical components used in the Freedom XC 2000 (230VAC) Inverter/Charger are made of recyclable material like steel, copper, aluminum, and other alloys. These materials can be auctioned off to traditional scrap metal recycling companies who resell reusable scraps.

  • Page 13: Table Of Contents

    CONTENTS Important Safety Instructions Installation Tools and Materials Product Safety Information Basic Installation Procedures Precautions When Working With Batteries Step 1: Designing the Installation Precautions When Placing the Unit Step 2: Choosing a Location for the Unit Regulatory Step 3: Mounting the Unit Emissions Step 4: Connecting the AC Input Wires End of Life Disposal...
  • Page 14 Physical Specifications Battery Charger Functions Environmental Specifications Battery Types System Specifications Custom Battery Settings Menu Regulatory Approvals Operating During Transition Between Grid Mode and Battery Mode Operating Limits Power Output Input Voltage Overload Conditions Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 15: Introduction

    INTRODUCTION The Freedom XC 2000 (230VAC) Inverter/Charger is designed with integrated inverting functions and power management features suitable for marine, recreational, and commercial/fleet vehicle installations. Please read this section to familiarize yourself with the main performance and protection features of the Freedom XC.

  • Page 16: Materials List

    Freedom Figure 1 What’s In The Box XC automatically becomes an independent NOTE: If any of the items are missing, contact Xantrex or any power source that supplies utility grade AC authorized Xantrex dealer for replacement. See Contact power to your loads.
  • Page 17 Materials List Comprehensive The Freedom XC’s built-in protection features Configurable AC The Freedom XC allows two speed settings Protection safeguard your batteries (from unnecessary Transfer Speed for the AC transfer from Grid Mode to Battery drain) such as the low battery voltage alarm Mode and vice versa which avoids nuisance and shutdown and protect equipment such as resetting of appliances.
  • Page 18 EU. The AC voltage Charging battery charging. This is the ability to setting can also be configured to either of recharge batteries, even if the battery voltage three settings: 220, 230, or 240 VV. has reached 0 VZ. Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 19 Materials List Load The Freedom XC has a built-in 30A transfer Management relay (Freedom XC 2000 (230VAC)) that connects the inverter/charger output or AC input from the AC generator to the loads. Because the usual AC power sources such as small generators often have limited current availability, having the capability to manage your AC loads is extremely valuable.
  • Page 20 This page is intentionally left blank. [2]...

  • Page 21: Features

    FEATURES This section identifies the default settings and the hardware features of the Freedom XC 2000 (230VAC) Inverter/Charger. This section includes: Default Settings AC and DC Panel Display Panel Side Panel 975-0821-01-01...

  • Page 22: Default Settings

    Disabled Inverter output frequency 50 Hz Inverter output voltage 230 VV Inverter power limit 2 kW Inverter power limit timer 300 s Appliance APL Transfer mode Utility AC under-voltage level 180 VV Inverter fault recovery Manual Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 23 Default Settings Program Item Default Setting Setting Audible alarm Battery type Flooded Battery temperature 14.4 VZ 14.4 Custom absorption voltage 13.5 VZ 13.5 Custom float voltage Charger current 80 AZ 2-stg 2-stage Charger algorithm 3-stg 3-stage Charger ignition control Equalize charge for flooded battery Disabled type AC input breaker...

  • Page 24: Ac And Dc Panel

    Ventilation grille (openings) must not be obstructed. Figure 2 AC and DC Panel Earthing lug provides an earth path for the Freedom XC chassis to the DC system earth. See WARNING. DC terminal opening for routing (–) negative DC cable. Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 25 AC and DC Panel Item Description WARNING DC terminal opening for routing (+) positive DC cable. ELECTRICAL SHOCK HAZARD LED alert indicator for reverse DC polarity. Use a torque screwdriver to tighten the bolt on the DC earth lug to a torque of 2.6 N-m of force. AC output terminal opening for routing AC output wiring.

  • Page 26: Display Panel

    Power button is pressed for turning on the unit. The inverter turns on for the loads and when applicable, the charger turns on automatically. Figure 3 Display Panel Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 27: Side Panel

    Side Panel Side Panel Table 4 Side Panel Features Item Description Captive nut panel screw holds the wiring compartment cover in place. See WARNING above. Wiring compartment cover protects the wiring compartment from debris and keeps the cables secure. Using the captive nut panel screw, the cover can be opened and lifted out during wiring.
  • Page 28 This page is intentionally left blank. [2]...

  • Page 29: Installation

    INSTALLATION Please read this section for safety information and installation instructions regarding your Freedom XC. This section includes: Before You Begin the Installation Installation Codes Installation Tools and Materials Basic Installation Procedures Step 1: Designing the Installation Step 2: Choosing a Location for the Unit Step 3: Mounting the Unit Step 4: Connecting the AC Input Wires Step 5: Connecting AC Output to an Existing AC Circuit...

  • Page 30: Before You Begin The Installation

    Disconnect from all power sources when servicing. Disable and secure all AC and DC disconnect devices and automatic generator starting devices. Failure to follow these instructions can result in death, serious injury, or equipment damage Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 31: Installation Tools And Materials

    Before You Begin the Installation Installation Tools and Materials You will need the following to install the Freedom XC: Wire stripper Mounting (M2.5) screws or bolts Phillips torque screwdriver Torque wrench for DC terminals (13mm socket wrench) AC cable (that is, two-conductor-plus-earth cable), sized appropriately for load and application PG16 (or PG21) strain relief clamps (for the AC cable clamp holes)
  • Page 32 This page is intentionally left blank. [2]...

  • Page 33: Basic Installation Procedures

    Basic Installation Procedures Basic Installation Procedures This section provides sample installation information as a guide for your installation. For your convenience, the overall procedure is divided into these main steps: Step 1: Designing the Installation Step 2: Choosing a Location for the Unit Step 3: Mounting the Unit Step 4: Connecting the AC Input Wires Step 5: Connecting AC Output to an Existing AC Circuit 33...

  • Page 34: Step 1: Designing The Installation

    Also, see "Marine Installation" on page 45. Equipment earth Freedom XC DC fuse/disconnect/DC circuit breaker 12V deep cycle battery [house] Battery isolator Alternator To engine Equipment earth Starting battery AC load panel AC source panel Selector switch Shore power Generator Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 35 Basic Installation Procedures AC Shore Power AC Disconnect and Over-Current Protection Device A source of 230 VV 50Hz sine wave alternating current provides energy to pass power through to AC loads. This source is usually Most safety requirements and electrical codes require the the utility grid (power company) or an AC generator.
  • Page 36 In other applications, flexible multiple-strand wire may be required. Installation codes usually specify solid or stranded, overall size of the conductors, and type and temperature rating of the insulation around the wire. Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 37 Basic Installation Procedures AC breakers and fuses must be sized to adequately protect the AC Output Neutral Bonding Option (Earth wiring that is installed on the input and output AC circuits of the Relay Function) Freedom XC. All breakers and wiring must be sized and The earth relay function allows you to connect the neutral connected in accordance with the electrical codes or regulations conductor (N) of the inverter output circuit to the safety earth...
  • Page 38 NOTE:It is not recommended using a cable longer than 1.5 meter) in each direction. IMPORTANT: Using the correct cable size is critical to achieving the rated performance of the Freedom XC unit. When starting a Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 39 Basic Installation Procedures heavy load the Freedom XC can draw current surges from the battery of up to 250A. If the DC wiring is too small the voltage drop from this surge will result in a voltage at the Freedom XC terminals that is too low for the Freedom XC to operate correctly.

  • Page 40: Step 2: Choosing A Location For The Unit

    Dry. Do not allow water or other fluids to drip or splash on the Freedom XC. Do not mount the Freedom XC in an area subject to splashing water or bilge water. Cool. Normal air temperature should be between 20 °C and 40 °C—the cooler the better. Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 41: Step 3: Mounting The Unit

    Basic Installation Procedures Figure 7 Approved Mounting Orientations Step 3: Mounting the Unit To mount the Freedom XC: 1. Remove the Freedom XC from its shipping container, verify that all components are present, and record relevant product information on “Information About Your System” in the Owner’s Guide.
  • Page 42 In general, the equipment earth cable size must not be smaller than one size than the supply cable. DC earthing lug Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 43: Step 4: Connecting The Ac Input Wires

    Basic Installation Procedures AC Wiring and RCBOs Step 4: Connecting the AC Input Wires AC wiring includes all the wires and connectors between the AC source and the Freedom XC and all wiring between the WARNING inverter/charger, the AC panels, RCBO (Type B), and circuit breakers.
  • Page 44 Install the supplied AC knockout plugs over the knockout holes when not used for wiring to prevent objects and other material from entering the unit. Failure to follow these instructions can result in equipment damage. Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 45 Basic Installation Procedures AC Input Connections Figure 9 Loosening the captive nut panel screw To make a permanent connection to existing AC wiring: 1. Ensure AC and DC power sources are turned off. 2. Install the required circuit breaker in the AC distribution panel supplying AC power to the unit.
  • Page 46 7. Locate the Neutral, Earth and Line terminals on the AC input 12. Connect the other end of the wires to the circuit breaker in terminal labeled as N, G, and L respectively. the AC distribution panel supplying AC power to the unit. Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 47: Step 5: Connecting Ac Output To An Existing Ac Circuit

    Basic Installation Procedures Step 5: Connecting AC Output to an NOTICE Existing AC Circuit EQUIPMENT DAMAGE Do not connect any AC source (such as a generator or WARNING utility power) to the AC output wiring of the Freedom ELECTRIC SHOCK AND FIRE HAZARDS The Freedom XC will not operate if its output is connected to AC voltage from another source, and potentially Make sure wiring is disconnected from all electrical sources...
  • Page 48 8. Make sure that each AC wire is matched and connected to 1. Ensure AC and DC power sources are turned off, if not the Neutral (N), Earth (G), and Line (L) connections. already done from AC Output Connections on page 34. Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 49 Basic Installation Procedures 9. Tighten the strain relief clamp to secure the wires. 10. Replace the wiring compartment cover (using a #2 Phillips torque screwdriver - see WARNING), if you are finished with connecting all the AC wires in the unit. WARNING ELECTRICAL SHOCK HAZARD Use a torque screwdriver to tighten the captive nut panel screw to...

  • Page 50: Step 6: Connecting The Dc Cables

    Use only stranded, copper wire rated minimum 105 °C. Make sure all DC connections are tight to a torque of 8–9 Nm of force. Loose connections will overheat. Failure to follow these instructions can result in death, serious injury, or equipment damage. Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 51 Basic Installation Procedures 6. Strip 13 to 19 mm of insulation from each cable end that will To make the DC connections: be connected to the inverter/charger cable. The amount 1. Make sure the inverter/charger is off and no AC or DC is stripped off will depend on the terminals chosen.
  • Page 52 Reversing the positive and negative battery cables will connected to the positive terminal of the battery. blow a fuse in the Freedom XC and void your warranty. Failure to follow these instructions can result in equipment damage. Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 53 Basic Installation Procedures 15. Replace the wiring compartment cover by tightening the WARNING captive nut panel screw. See the following electrical shock hazard warning. FIRE HAZARD WARNING Do not complete the next step if flammable fumes are present. Explosion or fire may result if the disconnect/battery selector switch ELECTRICAL SHOCK HAZARD is not in the off position.
  • Page 54 Use stranded, copper wire that is bare or has insulation rated minimum 105 °C, and connect it between the Chassis Earth lug and the boat’s DC earthing bus or engine negative bus. Use a wire of gauge 53.5mm minimum. See regulatory references below. Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 55: Step 7: Connecting To Port(S) On The Freedom Xc

    Basic Installation Procedures Figure 13 Ignition signal (ACC) input terminal Step 7: Connecting to Port(s) on the Freedom XC Connecting to ACC Signal With the ACC, the Freedom XC can be wired to inhibit inverter operation in the absence of a vehicle’s (or vessel's) +12VZ ignition control signal.
  • Page 56 To completely disable the ignition control features do the following: Off (OFF) Set Ignition Control to Off (OFF) using the Select buttons on the Display panel. Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 57: Step 8: Testing Your Installation

    Basic Installation Procedures Testing in Battery Mode Step 8: Testing Your Installation To test the Freedom XC: 1. For hard wired installations, ensure shore power is not WARNING present. 2. Press the Power button to turn the inverter/charger on. ELECTRIC SHOCK HAZARD The green LED indicating Battery mode (Inverter mode) Pressing the Power button to turn the Freedom XC inverter to turns on and the LCD screen displays the BATT.
  • Page 58 NOTE: In the event of low or no battery voltage, shore power will pass through the Freedom XC to the output even when shore power is outside the normal operating range. Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 59: Marine Installation

    Marine Installation Marine Installation Figure 14 Typical Marine Installation Figure 14 illustrates a typical marine installation with the following components: Equipment earth – Engine negative bus / DC earth bus Freedom XC DC fuse/disconnect/DC circuit breaker 12V deep cycle battery bank (house) and protected by a DC fuse in the positive cable Battery isolator DC alternator...

  • Page 60: Drip Shield Installation

    Figure 16 Typical Drip Shield Placement on a Freedom XC Failure to follow these instructions can result in death, serious injury, or equipment damage. You may purchase the drip shield set by contacting customer support. When ordering, mention part number 808-1050. Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 61: Operation

    OPERATION This section includes descriptions of the different modes and settings of the Freedom XC 2000 (230VAC) Inverter/Charger. This section includes: Freedom XC Display Panel Status LED Indicators Function Buttons LCD Screen LCD Screen Icons 975-0821-01-01...

  • Page 62: Freedom Xc Display Panel

    "Function Buttons" on the facing page error codes, see Motor Loads on page 82. see "Function Buttons" on the facing page NOTE: Briefly pressing any function button activates backlight illumination. After 60 s of inactivity, backlight illumination turns off. Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 63: Function Buttons

    Freedom XC Display Panel Function Buttons LCD Screen The LCD Screen changes depending on the operating mode of the Button Definition inverter/charger. Figure 18 Parts of the LCD Screen Return to default screen or exit setting mode Next screen or next selection Press and hold for 3 s to go back one step To enter the setting mode or to confirm the setting INPUTBATTTEMP...

  • Page 64: Lcd Screen Icons

    One bar = 1-25%, two bars conversion from DC to AC - inverting. = 25-50%, three bars = 50-75%, and four bars = 75-100%. The alarm buzzer is muted. Shows an overload condition. Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 65: Viewing Information During Battery Mode

    Viewing Information During Battery Mode Viewing Information During Info and Setting LCD Screen Battery Mode The LCD screen displays information related to battery mode operation. Screen 2 of 4 - Press the Scroll button to move from screen to screen. AC Output Press and hold for 3 s to go back one step.
  • Page 66 Viewing Information During Battery Mode Info and Setting LCD Screen Screen 4 of 4 - Firmware version Firmware version = U1 1.01 Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 67: Viewing Information During Grid Mode

    Viewing Information During Grid Info and LCD Screen Mode Setting 1. The LCD screen displays information related to AC bypass or charger operation. 2. Press the Scroll button to move from screen to screen. 3. Press to return to the home screen. Screen 1 of NOTE: After 1 min of inactivity in the other screens, the LCD will 5 - Battery...
  • Page 68 = 230VV, input frequency = 50Hz Screen 3 of Screen 5 of AC input current/AC Firmware load version current input current = 15.6A, load current = 6.8A Firmware version = U1 1.01 Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 69: Adjusting Feature Settings In Configuration Mode

    Adjusting Feature Settings in Configuration Mode Adjusting Feature Settings in To change the default value to a different value: 1. Press and hold the button for 3 s to enter the feature Configuration Mode settings mode. 2. Press the Scroll button to move through the different , Scroll , and buttons can be used to cycle...

  • Page 70: Settings

    Power Save Time setting after 25 is OFF. ENA (enable), Power Save (Load When enabled, the inverter/charger’s “no load” loss can be DIS (disable) Sensing) Mode reduced further when total load is less than 25 W. Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 71 Inverter Output Power The wattage setting value can be adjusted by 100-W increments. 0.1 to 2.0 Limit (Freedom XC 2000 Use with Inverter Output Power Limit Timer especially when (230VAC)) pairing with a lithium ion battery. 0.1 is equivalent to 100 W.
  • Page 72 Selecting Cold from Hot will increase charger voltage by 0.8V. HOT(Hot) Custom Absorption 14.6 12.0 to 17.0 The voltage setting value can be adjusted by 0.1 increments. Voltage Available only when custom battery type is selected. 13.5 12.0 to 17.0 Custom Float Voltage Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 73 Setting Name Description Number Value Values Charger Current 5 to 80 (Freedom XC 2000 The current setting value can be adjusted by 5A increments. (230VAC)) OFF(OFF) Charger Ignition Control See Description of Ignition Control Features on page 42. AT0 (Auto-ON)

  • Page 74: Operating In Battery Mode

    NOTE: Certain types of loads can cause power save mode to work unexpectedly. These types of loads are described in BATT.MODE Problem Loads on page 83. Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 75: Checking Battery Status

    Operating in Battery Mode Any warnings such as error or fault conditions or imminent Checking Battery Status shutdown are both displayed on the LCD screen and sounded on During inverter operation (in battery mode), you can check the the alarm speakers. See To manually reset the alarm: on page 61. battery status by observing the battery capacity indicator on the Audible alarm for warning: The unit beeps once when a warning LCD screen.

  • Page 76: Operating In Grid Mode

    Operating in Grid Mode Operating in Grid Mode Battery Types The Freedom XC 2000 (230VAC) Inverter/Charger charges flooded (or wet) lead-acid, Gel, AGM (absorbed glass mat), Battery Charger Functions custom, and lithium iron phosphate (LFP) batteries. When AC power is available, the Freedom XC can operate as a Flooded (or wet) batteries have removable battery caps for 12-VZ battery charger.
  • Page 77 Operating in Grid Mode There is a fourth stage, equalization, which is initialized manually NOTICE as it is only performed occasionally and only on flooded (or wet) batteries. BATTERY DAMAGE The charging cycle is a multistage (three-stage) process. Do not mix battery types. The Freedom XC can only select one battery type setting for all batteries connected to its bank.
  • Page 78 Preset Float Voltage The charge current allowed by the batteries falls below the exit Flooded 13.5 current threshold, which is equal to 10% of the programmed 13.8 charge current and a minimum of 2A. Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 79 Operating in Grid Mode Equalize Charging Battery Type Preset Float Voltage Many battery manufacturers recommend periodic equalize 13.4 charging to counter cell charge imbalance and capacity-robbing electrolyte stratification. Equalizing helps to improve battery 13.4 performance and lifespan by encouraging more of the battery 13.5 (default), changeable between 12.0 Custom material to become active.

  • Page 80: Custom Battery Settings Menu

    Custom battery type can be selected by the setting number 20 (see Custom Battery Settings Menu on page 66). After the custom battery is selected, you can then adjust the value of custom absorption (setting number 22) and custom float (setting number 23) accordingly. Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 81: Operating During Transition Between Grid Mode And Battery Mode

    Operating During Transition Between Grid Mode and Battery Mode Operating During Transition Operating Limits These are the operating limits of the Freedom XC: Between Grid Mode and Battery Power Output Mode Input Voltage The Freedom XC’s advanced power management is capable of Overload Conditions transitioning power from an AC source to DC source within a High Surge Loads...

  • Page 82: Power Output

    To set LBCO, see Adjusting Feature Settings in Configuration Mode on page 55. ambient to 1500 W before the over-temperature shutdown occurs at 60°C ambient. See Specifications on To set LBCO Shutdown Delay Timer, see Input Voltage on page 68. page 85. Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 83 Operating During Transition Between Grid Mode and Battery Mode Operating Battery Operating Battery Comment Comment Condition Voltage Condition Voltage The buzzer sounds a single 1 s The display shows error code E02 alternating with the battery low battery alarm beep and the LCD screen shows error code voltage.

  • Page 84: Overload Conditions

    Freedom XC may not be able to start some of these motors even though their rated steady state current draw is within the inverter/charger’s limits. The unit will shut down and indicate an overload shutdown. Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 85: Routine Maintenance

    5 ROUTINE MAINTENANCE Regular maintenance is required to keep your Freedom XC operating properly. This section includes: Maintaining the Freedom XC Unit 975-0821-01-01...

  • Page 86: Maintaining The Freedom Xc Unit

    With all sources of power off, clean the exterior of the unit with a damp cloth to prevent the accumulation of dust and dirt. Ensure that the DC cables are secure and fasteners are tight. Make sure the ventilation openings are not clogged. Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 87: Troubleshooting

    TROUBLESHOOTING This section will help you narrow down the source of any problem you encounter. Before contacting customer service, please work through the steps listed in Pre-service Checklist on page 74. This section includes: Pre-service Checklist Warning Messages Troubleshooting Reference 975-0821-01-01...

  • Page 88: Pre-Service Checklist

    What loads the Freedom XC was running or attempting to run What the battery condition was at the time (voltage, etc.) if known Recent sequence of events Any known unusual AC shore power factors such as low voltage, unstable generator output, etc. Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 89: Warning Messages

    Warning Messages Warning Messages Warning messages in the form of audible alarms and error codes that appear on the LCD screen to alert you to an impending system change. Warnings do not affect operation. With the exception of the error codes displayed on the screen, only the audible alarm can be turned ON or OFF.
  • Page 90 Over-temperature shutdown (inverting) Check for ambient temperature and move the unit to a cooler location whenever possible. Battery mode AC output overload warning Reduce the loads connected to the AC outlet of the unit. (inverting) Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 91 Warning Messages Error Code Condition Mode Action Reduce the loads connected to the AC outlet of the unit. Check that the ventilation grille is not blocked. Over-temperature alarm Battery mode Check for ambient temperature and move the unit to a cooler and fan lock alarm (inverting) location whenever possible.

  • Page 92: Troubleshooting Reference

    Avoid continually overloading the inverter/charger and subjecting it to over temperature conditions. Although provided with integral protection against overloads continual overloading can damage the circuitry. Failure to follow these instructions can result in damage to the inverter/charger. Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 93 Troubleshooting Reference Table 15 Troubleshooting reference Problem Possible Cause Solution Alarm does not sound when an error is Alarm is turned OFF. See Maintaining the Freedom XC Unit on page 72 and encountered. follow instructions to turn the alarm buzzer on again. No output voltage.
  • Page 94 OFF Turn the inverter/charger ON and look at the LCD due to a shutdown for more than screen for any error code. 30 s. See "Problem" on the previous page. Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 95 Troubleshooting Reference Problem Possible Cause Solution No output voltage. The status LED is Ignition lock (ACC) signal is not If the ignition control feature is in use, ensure the not lighting up. present. vehicle’s ignition is On and the ignition control switch on the front of the Freedom XC unit is On (|).

  • Page 96: Inverter Applications

    To avoid this effect, do not connect motor loads together with sensitive equipment to the inverter/charger for power. Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 97: Problem Loads

    Inverter Applications When the Freedom XC is in power save mode, it may fail to start Problem Loads some loads even though the rated wattage on the load is more Very Small Loads If the power consumed by a device is less than 25 W.
  • Page 98 This page is intentionally left blank. [2]...

  • Page 99: Specifications

    SPECIFICATIONS This section summarizes the hardware and electrical specifications of the Freedom XC 2000 (230VAC) Inverter/Charger. This section includes: Physical Specifications Environmental Specifications System Specifications Regulatory Approvals NOTE: Specifications are subject to change without prior notice. 975-0821-01-01...

  • Page 100: Physical Specifications

    IP21 (marine installation with drip shield accessories) Operation may be limited based on the battery chemistry. For example, Lithium Iron Phosphate batteries have a limited charging temperature range. Follow specific battery manufacturer recommendations for the applicable chemistry. Freedom XC 2000 (230VAC) Owner's Guide...

  • Page 101: System Specifications

    System Specifications System Specifications Table 20 DC input for inverting Freedom XC 2000 (230VAC) Table 19 System specifications 10–17.0 V Z Operating voltage range Freedom XC 2000 (230VAC) Maximum non-operating voltage 25.2 V Z Transfer relay rating (A 30AV 12.0 V Z...

  • Page 102: Regulatory Approvals

    Compliance with CE Marking: Restriction of Specific Hazardous Environmental Substances (RoHS) Directive (2011/65/EU and amendments) Charger current is rated to 14.4 V Z output only. The charger derates if a high Z output voltage is selected. Freedom XC 2000 (230VAC) Owner's Guide...
  • Page 103 This page is intentionally left blank. [2]...
  • Page 104 (Toll Free USA/Canada) +1 800 670 0707 (Outside USA/Canada) +1 408 987 6030 Printed in: 975-0821-01-01 Rev B...
