Electrical Installation
5 5
1
2
3
4
L1
L2
L3
PE
5
1 PLC
2
Minimum 16 mm
3 Control cables
4 Minimum 200 mm (7.9 in) required between control cables,
motor cables, and mains cables.
5 Mains supply
6 Bare (unpainted) surface
7 Star washers
8 Brake cable (shielded)
9 Motor cable (shielded)
Illustration 5.1 Example of Proper EMC Installation
24
VLT® Refrigeration Drive FC 103
2
(6 AWG) equalizing cable
Danfoss A/S © 04/2018 All rights reserved.
90
4
4
PE
10 Mains cable (unshielded)
11 Output contactor and similar options
12 Cable insulation stripped
13 Common ground busbar. Follow local and national
requirements for enclosure grounding.
14 Brake resistor
15 Metal box
16 Connection to motor
17 Motor
18 EMC cable gland
6
7
8
9
10
11
12
13
14
15
u
16
v
w
17
18
