Specifications
Resolution of frequency outputs
1) Terminals 27 and 29 can also be programmed as inputs.
The digital output is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
Control card, 24 V DC output
Terminal number
Maximum load
The 24 V DC supply is galvanically isolated from the supply voltage (PELV), but has the same potential as the analog and digital
inputs and outputs.
Relay outputs
Programmable relay outputs
Maximum cross-section to relay terminals
Minimum cross-section to relay terminals
Length of stripped wire
Relay 01 terminal number
Maximum terminal load (AC-1)
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
Maximum terminal load (DC-13)
Maximum terminal load (AC-1)
9 9
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
Maximum terminal load (DC-13)
Minimum terminal load on 1–3 (NC), 1–2 (NO)
Environment according to EN 60664-1
Relay 02 terminal number
Maximum terminal load (AC-1)
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
Maximum terminal load (DC-13)
Maximum terminal load (AC-1)
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
Maximum terminal load (DC-13)
Minimum terminal load on 4–6 (NC), 4–5 (NO)
Environment according to EN 60664-1
1) IEC 60947 part 4 and 5.
The relay contacts are galvanically isolated from the rest of the circuit by reinforced isolation (PELV).
2) Overvoltage Category II.
3) UL applications 300 V AC 2 A.
Control card, +10 V DC output
Terminal number
Output voltage
Maximum load
The 10 V DC supply is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
Control characteristics
Resolution of output frequency at 0–1000 Hz
System response time (terminals 18, 19, 27, 29, 32, 33)
Speed control range (open loop)
86
VLT® Refrigeration Drive FC 103
1) on 1–2 (NO) (Resistive load)
on 1–2 (NO) (Inductive load @ cosφ 0.4)
1)
1)
on 1–2 (NO) (Resistive load)
1)
on 1–2 (NO) (Inductive load)
1)
on 1–3 (NC) (Resistive load)
on 1–3 (NC) (Inductive load @ cosφ 0.4)
1)
1)
on 1–3 (NC) (Resistive load)
1)
on 1–3 (NC) (Inductive load)
1)
on 4–5 (NO) (Resistive load)
on 4–5 (NO) (Inductive load @ cosφ 0.4)
1)
1)
on 4–5 (NO) (Resistive load)
1) on 4–5 (NO) (Inductive load)
1)
on 4–6 (NC) (Resistive load)
on 4–6 (NC) (Inductive load @ cosφ 0.4)
1)
1)
on 4–6 (NC) (Resistive load)
1)
on 4–6 (NC) (Inductive load)
Danfoss A/S © 04/2018 All rights reserved.
2) , 3)
Overvoltage category III/pollution degree 2
2) 3)
,
Overvoltage category III/pollution degree 2
12 bit
12, 13
200 mA
2
2.5 mm (12 AWG)
2
0.2 mm (30 AWG)
8 mm (0.3 in)
1–3 (break), 1–2 (make)
400 V AC, 2 A
240 V AC, 0.2 A
80 V DC, 2 A
24 V DC, 0.1 A
240 V AC, 2 A
240 V AC, 0.2 A
50 V DC, 2 A
24 V DC, 0.1 A
24 V DC 10 mA, 24 V AC 2 mA
4–6 (break), 4–5 (make)
400 V AC, 2 A
240 V AC, 0.2 A
80 V DC, 2 A
24 V DC, 0.1 A
240 V AC, 2 A
240 V AC, 0.2 A
50 V DC, 2 A
24 V DC, 0.1 A
24 V DC 10 mA, 24 V AC 2 mA
50
10.5 V ±0.5 V
25 mA
±0.003 Hz
≤2 m/s
1:100 of synchronous speed
