9.9 Enclosure Airflow
9.9.1 Airflow for E1h–E4h Enclosures
9
9
Illustration 9.18 Standard Airflow Configuration for E1h/E2h (Left) and E3h/E4h (Right)
Illustration 9.19 Optional Airflow Configuration Through the Back Wall for E1h/E2h (Left) and E3h/E4h (Right)
104
VLT® Refrigeration Drive FC 103
225 mm (8.9 in)
Danfoss A/S © 04/2018 All rights reserved.
225 mm (8.9 in)
225 mm (8.9 in)
225 mm (8.9 in)
MG16P222
