3] Control Menu - Mecmesin MultiTest-x Series Operating Instructions Manual

Once the limits of the first calculation have been specified, pressing [Start/ENT] will
display the screen associated with specifying the limits of the second calculation...
...and once the limits of the final calculation have been specified, pressing
[Start/ENT] will display the Analysis menu (see [1], [3], [2] ).
[1], [3], [2], <3> Auto XMit Res-OFF
Pressing [3] will toggle between options available (OFF or ON)
If the 'ON' option has been selected, when a test has been completed results will
automatically be downloaded to a PC or datalogger via the RS232 port on the rear
control panel. The option will remain after each individual test to decide whether
results should be downloaded (see [1], [2], [1] Send Test Results).
[1], [3], [2], [4] Calculate Results
a)
either no calculations are associated with the current procedure, or if no data
exist from which to calculate results
b)
being re-calculated
Note that if data from some cycles are being discarded while a test is running (see [1],
[3], [3], [1], (j), Set Cyclic Logging) and if any result being reported uses an
'occurrence' parameter (see [1], [3], [2], <1> Select Analysis) there is a chance that an
unexpected result could be reported – unless, when specifying the occurrence
parameter, due account is taken of the fact that results will be based only upon data
for those cycles which have been recorded.

[1], [3], [3] Control Menu

Mecmesin MultiTest-x manual
this is the message that will be displayed if
will appear on the bottom line while results are
26
