[1], [2], [1] Send Test Results

Test results available will be sent via RS232 port on rear panel, i.e. data can be
downloaded to PC or data logger.

[1], [2], [2] Send XY Data

XY data available will be sent via RS232 port on rear panel.

[1], [2], [3] Send Procedure

Procedure will be sent via RS232 port on rear panel.

[1], [2], [4] Send Calibration

Calibration information will be sent via RS232 port on rear panel.
Notes:
a) The four print commands above are generically similar, they all send data
to the RS232 port. If there is an RS232 cable attached to the appropriate
connector on the test stand, and if the cable connects to a PC or
datalogger and appropriately-configured software is active, then, and only
then, the data sent can be archived. However if, for example, the cable is
not connected, such an error cannot be detected and no warning message
will be generated by the MultiTest-x software
b) It is possible to specify a 'Batch ID' and a 'User ID', which will be archived
with some of the data downloaded with the above four print commands:
•
Press [Batch#] key from the 'live screen'
