1.25

PORT PRIORITY CONFIGURATION SCREEN

The Port Priority Configuration screen,
priority (0 through 7) on a port. A frame received without priority
information in its tag header is assigned a priority according to the
priority setting on the port. For example, if the priority of a port is set to 5,
all frames received through that port without priority indicated in their tag
header are classified as a priority 5.
A frame with priority information in its tag header will be placed in the
priority queue according to the priority indicated in its tag header.
The Port Priority Configuration screen does not display when
NOTE
the operational mode of the module is set to 802.1D
SWITCHING.
To access the Port Priority Configuration screen from the 802.1p Priority
Configuration screen, use the arrow keys to highlight the PORT
PRIORITY CONFIGURATION menu item and press ENTER. The
Port Priority Configuration screen displays.
Port #
SAVE
Figure 1-24 Port Priority Configuration Screen
Local Management Supplement
Priority
1 [0]
2 [2]
3 [2]
4 [3]
5 [3]
6 [4]
7 [4]
8 [0]
9 [5]
10 [6]
11 [6]
12 [7]
Set All Switch Port's Priority
PREVIOUS
Port Priority Configuration Screen
Figure 1-24, is used to set a
Port #
13
14
14
16
17
18
19
20
21
22
23
24
[3]
NEXT
EXIT
Priority
[4]
[4]
[4]
[4]
[4]
[6]
[6]
[6]
[1]
[1]
[1]
[1]
RETURN
2762-87
1-63
